SYX GF32LO Hydraulic Cylinder Rod Ends With Welding Shank INA GF32LO
Price:
3.66 usd/pc to 3.84 usd/pc
MOQ:
50
Delivery Time:
30 working days
Brand:
SYX
Product Description
SYX GF32LO Hydraulic Cylinder Rod Ends with Welding Shank
SYX hydraulic cylinder rod ends with welding shank are precision-engineered components designed for demanding hydraulic applications. These rod ends combine a robust rod end housing with a radial spherical plain bearing, secured in place by snap rings for reliable performance.
Product Design & Construction
Available in two primary configurations: rod ends with welding shank and rod ends with locking slot. The welding shank variant is manufactured from weldable steel and features two shank profiles - prismatic and cylindrical. The cylindrical shank includes an elastic pin at the base for simplified positioning and alignment during installation.
Rod ends with locking slot are typically constructed from carbon steel or spheroidal graphite cast iron. These feature female threading in the rod end body and are supplied with fastening screws for secure mounting.
Lubrication & Performance
Hydraulic rod ends support periodic re-lubrication through integrated oil cups or via holes in the rod end body. The steel-to-steel construction provides exceptional wear resistance, while the high-strength sliding surfaces make these bearings ideal for applications involving heavy alternating loads or significant static loads.
Technical Specifications
| Model | d (mm) | B (mm) | dk (mm) | C1 (mm) | d2 (mm) | h (mm) | l2 (mm) | rs (mm) | Dynamic Load (KN) | Static Load (KN) | ≈a" | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| GF20LO | 20 | 20 | 29 | 19 | 50 | 38 | 63 | 0.3 | 30 | 67 | 4 | 0.370 |
| GF25LO | 25 | 25 | 35.5 | 23 | 55 | 45 | 72.5 | 0.6 | 48 | 69 | 4 | 0.540 |
| GF32LO | 32 | 32 | 43 | 27 | 70 | 65 | 100 | 0.6 | 65 | 168 | 4 | 1.160 |
| GF40LO | 40 | 40 | 53 | 35 | 100 | 69 | 119 | 0.6 | 99 | 305 | 4 | 2.570 |
| GF50LO | 50 | 50 | 66 | 40 | 123 | 88 | 149.5 | 0.6 | 156 | 441 | 4 | 4.500 |
| GF63LO | 63 | 63 | 83 | 50 | 145 | 107 | 179.5 | 1 | 253 | 591 | 4 | 7.140 |
| GF70LO | 70 | 70 | 92 | 55 | 164 | 115 | 197 | 1 | 313 | 724 | 4 | 10.860 |
| GF80LO | 80 | 80 | 105 | 60 | 180 | 141 | 231 | 1 | 400 | 804 | 4 | 15.830 |
| GF90LO | 90 | 90 | 115 | 65 | 226 | 150 | 263 | 1 | 488 | 1340 | 4 | 24.000 |
| GF100LO | 100 | 100 | 130 | 70 | 250 | 170 | 295 | 1 | 607 | 1516 | 4 | 33.440 |
| GF110LO | 110 | 110 | 140 | 80 | 295 | 185 | 332.5 | 1 | 654 | 2340 | 4 | 49.460 |
Product Images
Key Specifications
Inner Bore Diameter Range: 20 mm to 110 mm
GF32LO Static Load Rating: 168 KN
GF32LO Dynamic Load Rating: 65 KN
