107cc EFI Underbone Motorcycle with Dual Shock Absorbers and 150kg Heavy-Duty Load Capacity
Price:
Price negotiable
MOQ:
100
Delivery Time:
12 weeks
Brand:
ZFYC
Product Description
Adopts a 4-speed semi-automatic clutch transmission for easy operation without frequent manual clutch control. It is agile in urban traffic and user-friendly even for new riders.
| Item | Specification | ||||||
| Engine Type | Single-cylinder, horizontal, air-cooled | ||||||
| Bore × Stroke | 52.4 mm × 49.5 mm | ||||||
| Displacement | 107 cc | ||||||
| Compression Ratio | 9.1 : 1 | ||||||
| Max. Power | 4.5 kW @ 8,000 rpm | ||||||
| Max. Torque | 6.5 N·m @ 6,000 rpm | ||||||
| Fuel System | Electronic Fuel Injection (EFI) | ||||||
| Ignition System | CDI | ||||||
| Starting System | Electric & kick start | ||||||
| Magneto | 12-pole DC | ||||||
| Transmission | 4-speed, semi-automatic clutch | ||||||
| Final Drive | Chain drive | ||||||
| Primary / Final Reduction Ratio | 4.059 / 2.714 | ||||||
| 1st Gear | 3.273 | ||||||
| 2nd Gear | 1.938 | ||||||
| 3rd Gear | 1.35 | ||||||
| 4th Gear | 1.043 | ||||||
| Front Suspension | Telescopic hydraulic fork | ||||||
| Rear Suspension | Dual shock absorbers | ||||||
| Front Brake | Drum brake | ||||||
| Rear Brake | Drum brake | ||||||
| Front Tire | 2.50-16 (standard tire / optional deep tread tire) | ||||||
| Rear Tire | 2.75-16 (standard tire / optional deep tread tire) | ||||||
| Front Wheel | Spoked wheel (optional steel rim) | ||||||
| Rear Wheel | Spoked wheel (optional steel rim) | ||||||
| Rear Carrier | Optional rear carrier / large rear carrier | ||||||
| Center Carrier | Optional | ||||||
| Overall Dimensions (L × W × H) | 1860 × 810 × 1250 mm | ||||||
| Wheelbase | 1200 mm | ||||||
| Seat Height | 750 mm | ||||||
| Ground Clearance | 110 mm | ||||||
| Net Weight | 94.4 kg | ||||||
| Max. Load Capacity | 150 kg | ||||||
| Max. Speed | 75 km/h | ||||||
| Climbing Ability | ≥ 12° | ||||||
| Fuel Tank Capacity | 3.1 L | ||||||
| Helmet Box Capacity | Full-face helmet | ||||||
| Headlight | LED, 12V 8W (low beam) / 12W (high beam) | ||||||
| Taillight | LED 1.2W (brake) / 1.2W (position) | ||||||
| Front Turn Signals | Dynamic indicator, halogen 10W / LED 0.8W | ||||||
| Rear Turn Signals | Dynamic indicator, halogen 10W / LED 0.8W | ||||||
| Logo Light | 0.3W | ||||||
| Battery | 12V 5Ah, maintenance-free gel battery | ||||||
| USB Charger | USB, 2A | ||||||
Custom motorcycle orders accepted
