97cc Air-Cooled Underbone Motorcycle with Hydraulic Suspension and 150kg Load Capacity for Durable Export
Price:
Price negotiable
MOQ:
100
Delivery Time:
5-12 weeks
Brand:
ZFYC
Product Description
With a lightweight net weight of just 90kg, it's highly agile and easy to handle, yet boasts a impressive maximum load capacity of 150kg, perfectly balancing passenger and cargo needs. Features a long 1220mm wheelbase for exceptional stability on the road, and a 780mm seat height for confident footing. Optional Front Middle Shelf and Large Rear Shelf provide ample storage space, easily fitting a full helmet. This all-rounder excels in both work and daily life.
| Specification | Details | |||||||
| Engine Type | 97cc, Air-Cooled, Single Cylinder, EFI | |||||||
| Bore × Stroke | 50 × 49.5 mm | |||||||
| Displacement | 97 cm³ | |||||||
| Compression Ratio | 9.1:1 | |||||||
| Max Power | 4.5 kW @ 8000 ± 500 rpm | |||||||
| Max Torque | 6.5 N·m @ 6000 ± 500 rpm | |||||||
| Ignition | CDI, Electronic Fuel Injection | |||||||
| Starting System | Kick start & Electric start | |||||||
| Magneto | 12V DC | |||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | |||||||
| Transmission Mode | Chain drive | |||||||
| 1st Gear Ratio | 3.273 | |||||||
| 2nd Gear Ratio | 1.938 | |||||||
| 3rd Gear Ratio | 1.35 | |||||||
| 4th Gear Ratio | 1.043 | |||||||
| Primary / Final Drive Ratio | 4.059 / 2.714 | |||||||
| Front Suspension | Hydraulic Fork | |||||||
| Rear Suspension | Twin Shock Absorbers | |||||||
| Front Brake | Disc Brake | |||||||
| Rear Brake | Drum Brake / Optional: Expandable Shoe | |||||||
| Front Tire | 2.50-16, Standard / Optional: Deep Tread Tire | |||||||
| Rear Tire | 2.75-16, Standard / Optional: Deep Tread Tire | |||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | |||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | |||||||
| Rear Shelf | Optional: Rear Shelf / Large Shelf | |||||||
| Middle Shelf | Optional: Yes / Default: No | |||||||
| Length × Width × Height | 1860 × 700 × 1270 mm | |||||||
| Wheelbase | 1220 mm | |||||||
| Seat Height | 780 mm | |||||||
| Min Ground Clearance | 130 mm | |||||||
| Net Weight | 90 kg | |||||||
| Max Load | 150 kg | |||||||
| Max Speed | 75 km/h | |||||||
| Climbing Ability | ≥12° | |||||||
| Fuel Tank Capacity | 3.1 L | |||||||
| Helmet Box Capacity | Fits full helmet | |||||||
| Headlight | LED Lens, 12V 8W (Low Beam) / 12W (High Beam) | |||||||
| Taillight | LED 1.2W (Brake Light) / 1.2W (Position Light), Standard 21W / 5W | |||||||
| Front Indicators | Standard 10W / LED 0.8W | |||||||
| Rear Indicators | Standard 10W / LED 0.8W | |||||||
| Logo Light | Standard 0.3W | |||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | |||||||
| Charger | USB 2A | |||||||
Custom motorcycle orders accepted
Wholesale from Factory
