UD110 Underbone Motorcycle with 107cc Engine, Lightweight 88.6kg Design, and 5-Spoke Aluminum Wheels for Agile Commuting
Price:
Price negotiable
MOQ:
100
Delivery Time:
5-12 weeks
Brand:
ZFYC
Product Description
UD110 Underbone Motorcycle, 107cc Horizontal Engine with Low Center of Gravity for Stable Riding, CDI Precise Ignition for Quick Start, Easy-Operating 4-Speed Automatic Clutch, 8-Pole Magneto for Adequate Power, Hydraulic Shocks to Absorb Bumps, Linear Front & Rear Drum Brakes, Stylish & Durable 5-Spoke Aluminum Wheels, Compact Body 1810×670×1100mm for Agile Maneuver, 1220mm Wheelbase for Stable Handling, 88.6kg Lightweight for Easy Control, 150kg Load for Family Use, Sturdy Export Model.
| Specification | Details | |||||
| Engine Type & Cylinder Arrangement | Single-cylinder, horizontal, air-cooled | |||||
| Displacement | 107 cc | |||||
| Bore × Stroke | 52.4 × 49.5 mm | |||||
| Compression Ratio | 9.1:1 | |||||
| Max Power | 4.8 kW @ 8000 ± 500 rpm | |||||
| Max Torque | 7.1 N·m @ 6000 ± 500 rpm | |||||
| Ignition | CDI | |||||
| Starting System | Kick & Electric Start | |||||
| Magneto | 8-pole, Full-wave AC | |||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | |||||
| Transmission Mode | Chain drive | |||||
| 1st Gear Ratio | 3.273 | |||||
| 2nd Gear Ratio | 1.938 | |||||
| 3rd Gear Ratio | 1.35 | |||||
| 4th Gear Ratio | 1.043 | |||||
| Primary / Final Drive Ratio | 4.059 / 2.714 | |||||
| Front Suspension | Hydraulic Fork | |||||
| Rear Suspension | Twin Shock Absorbers | |||||
| Front Brake | Drum | |||||
| Rear Brake | Drum | |||||
| Front Tire | 2.50-17, Standard | |||||
| Rear Tire | 2.75-17, Standard | |||||
| Front Wheel | 5-Spoke Aluminum Wheel | |||||
| Rear Wheel | 5-Spoke Aluminum Wheel | |||||
| Rear Carrier | Small Shelf | |||||
| Middle Shelf | Steel Bars | |||||
| Overall Length × Width × Height | 1810 × 670 × 1100 mm | |||||
| Wheelbase | 1220 mm | |||||
| Seat Height | 760 mm | |||||
| Min Ground Clearance | 165 mm | |||||
| Net Weight | 88.6 kg | |||||
| Max Load | 150 kg | |||||
| Max Speed | 85 km/h | |||||
| Climbing Ability | ≥12° | |||||
| Fuel Tank Capacity | 3 L | |||||
| Helmet Box Capacity | Fits Half Helmet | |||||
| Headlight | Standard Bulb 12V 35W/5W | |||||
| Taillight | Standard Bulb 12V 21W/5W | |||||
| Front Indicators | Standard Bulb 12V 10W | |||||
| Rear Indicators | Standard Bulb 12V 10W | |||||
| Battery | 12V 5Ah | |||||
Wholesale from Factory
Custom motorcycle orders accepted
