China 107cc Engine Underbone Motorcycle with 150kg Load Capacity and Telescopic Hydraulic Fork for Commuting for sale

107cc Engine Underbone Motorcycle with 150kg Load Capacity and Telescopic Hydraulic Fork for Commuting

Price Negotiable

Price: Negotiable

MOQ: 100

Delivery Time: 5-12 weeks

Brand: ZFYC

Product Description

The lightweight design highlights handling advantages, with a curb weight of 95kg and a wheelbase of 1260mm, which is flexible and easy to control, even for beginners. The combination of front telescopic hydraulic fork and rear swing arm shock absorber effectively filters road bumps and improves riding comfort; front disc and rear drum brakes paired with 2.50-17 front and rear tires ensure sensitive braking and stable grip, escorting every ride.

Overall Length		1910 mm
Overall Width		690 mm
Overall Height		1130 mm
Wheelbase		1260 mm
Seat Height		850 mm
Footpeg Height		120 mm
Curb Weight		95 kg
Max Load		150 kg
Front Suspension		Telescopic Hydraulic Fork
Rear Suspension		Single/Double Swing Arm, Shock Absorber
Front Tire		2.50-17
Rear Tire		2.50-17
Front Brake		Disc
Rear Brake		Drum
Fuel Tank Capacity		4 L
Engine Type		CB, Single-cylinder, 4-Stroke, Air-Cooled
Cylinder Arrangement		Horizontal
Bore × Stroke		52.4 × 49.5 mm
Displacement		107 cc
Max Power		5.2 kW @ 7500 rpm
Max Torque		7.0 N·m @ 6000 rpm
Max Speed		80 km/h
Compression Ratio		9.2:1
Lubrication System		Pressure & Splash
Cooling System		Air-Cooled
Engine Dry Weight		21 kg
Fuel Supply Type		Carburetor
Clutch Type		Multi-plate Wet, Automatic
Transmission		Chain Drive
Primary Drive Ratio		4.059
Final Drive Ratio		2.571
1st Gear Ratio		2.883
2nd Gear Ratio		1.705
3rd Gear Ratio		1.238
4th Gear Ratio		0.958
Gear Shift Pattern		1-2-3-4, sequential
Ignition System		CDI
Starting System		Kick & Electric Start
Charging System		12V, Single Phase, 8-pole
Regulator/Rectifier		Full-Wave
