97cc EFI Fuel-Injected Underbone Motorcycle with 4-Speed Automatic Clutch and 90kg Lightweight Design
Price:
Price negotiable
MOQ:
100
Delivery Time:
5-12 weeks
Brand:
ZFYC
Product Description
97cc single-cylinder horizontal engine with EFI fuel injection + CDI ignition, featuring precise fuel supply and smooth start. Kick & electric start works well in complex environments. 4-speed automatic clutch with high gear protection is easy to operate for beginners; 90kg lightweight body + 1220mm wheelbase is flexible, suitable for shuttling in urban and rural areas. Front disc and rear drum brakes are sensitive, and LED lens headlight is bright enough for safer driving.
| Specification | Details | ||||||
| Engine Type & Cylinder Arrangement | Single-cylinder, horizontal | ||||||
| Displacement | 97 cc | ||||||
| Bore × Stroke | 50 × 49.5 mm | ||||||
| Compression Ratio | 9.1:1 | ||||||
| Max Power | 4.5 kW @ 8000 ± 500 rpm | ||||||
| Max Torque | 6.5 N·m @ 6000 ± 500 rpm | ||||||
| Ignition | Electronic Fuel Injection (EFI), CDI | ||||||
| Starting System | Kick & Electric Start | ||||||
| Magneto | 12-pole DC | ||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | ||||||
| Transmission Mode | Chain drive | ||||||
| 1st Gear Ratio | 3.273 | ||||||
| 2nd Gear Ratio | 1.938 | ||||||
| 3rd Gear Ratio | 1.35 | ||||||
| 4th Gear Ratio | 1.043 | ||||||
| Primary / Final Drive Ratio | 4.059 / 2.714 | ||||||
| Front Suspension | Hydraulic Fork | ||||||
| Rear Suspension | Twin Shock Absorbers | ||||||
| Front Brake | Disc | ||||||
| Rear Brake | Drum / Expandable Shoe | ||||||
| Front Tire | 2.50-16, Standard / Optional: Deep Tread Tire | ||||||
| Rear Tire | 2.75-16, Standard / Optional: Deep Tread Tire | ||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Carrier | Optional: Rear Shelf / Large Shelf | ||||||
| Middle Shelf | Optional: Yes / Default: No | ||||||
| Overall Length × Width × Height | 1860 × 700 × 1270 mm | ||||||
| Wheelbase | 1220 mm | ||||||
| Seat Height | 780 mm | ||||||
| Min Ground Clearance | 130 mm | ||||||
| Net Weight | 90 kg | ||||||
| Max Load | 150 kg | ||||||
| Max Speed | 75 km/h | ||||||
| Climbing Ability | ≥12° | ||||||
| Fuel Tank Capacity | 3.1 L | ||||||
| Helmet Box Capacity | Fits Full Helmet | ||||||
| Headlight | LED Lens, Low Beam 8W / High Beam 12W | ||||||
| Taillight | LED 1.2W (Brake) / 1.2W (Position), Standard 21W / 5W | ||||||
| Front Indicators | Standard 10W / LED 0.8W | ||||||
| Rear Indicators | Standard 10W / LED 0.8W | ||||||
| Logo Light | Standard 0.3W | ||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | ||||||
| Charger | USB 2A | ||||||
Custom motorcycle orders accepted
