225ml Off-Road Motorcycle with 12kW High Power, 5-Speed International Gear, and 230mm High Ground Clearance for Off-Road & Commuting
Price:
Price negotiable
MOQ:
100
Delivery Time:
5-12 weeks
Brand:
ZFYC
Product Description
225ml single-cylinder horizontal air-cooled engine delivers 12kW high power and 17.5N·m strong torque. 5-speed international gear with chain drive ensures smooth power output, making off-road shuttling more powerful. Kick & electric start + CDI communication ignition for quick and stable start, suitable for complex off-road environments; 230mm high ground clearance + ≥28° climbing ability, easily conquer rough roads and cope with complex terrain calmly.
| Specification | Description | ||||||
| Number of cylinders and engine angle | Single-cylinder, horizontal, air-cooled | ||||||
| Bore × Stroke | 65.5 × 66.6 mm | ||||||
| Displacement | 225 ml | ||||||
| Compression ratio | 9.0 : 1 | ||||||
| Max output power | 12 kW / 7500 ± 500 r/min | ||||||
| Max torque | 17.5 N·m / 7500 ± 500 r/min | ||||||
| Ignition system | CDI Communication, DC-CDI | ||||||
| Starting system | Foot & electric start | ||||||
| Magneto | 8 Grade DC | ||||||
| Gear and clutch | 5-speed international | ||||||
| Transmission mode | Chain drive | ||||||
| Primary gear ratio | 3.333 | ||||||
| 1st gear ratio | 2.909 | ||||||
| 2nd gear ratio | 1.866 | ||||||
| 3rd gear ratio | 1.388 | ||||||
| 4th gear ratio | 1.15 | ||||||
| 5th gear ratio | 0.954 | ||||||
| Front suspension | Smooth hydraulic fork (inverted) | ||||||
| Rear suspension | Spring shock absorber (single spring) | ||||||
| Front brake | Optional: front disc brake | ||||||
| Rear brake | Expandable shoe / drum, optional rear disc | ||||||
| Front tire | 90/100-21, optional deep gear tire | ||||||
| Rear tire | 110/100-18, optional deep gear tire | ||||||
| Front wheel | Spoked wheel, optional inverted disc spoked wheel | ||||||
| Rear wheel | Spoked wheel, optional disc spoked wheel | ||||||
| Flat fork | Rectangular tube flat fork, disc brake swing arm | ||||||
| Rear shelf | Optional rear shelf | ||||||
| Dimensions (L×W×H) | 2100 × 850 × 1210 mm | ||||||
| Wheelbase | 1440 mm | ||||||
| Seat height | 910 mm | ||||||
| Ground clearance | 230 mm | ||||||
| Net weight | 142 kg | ||||||
| Max load | 150 kg | ||||||
| Max speed | 96.4 km/h | ||||||
| Climbing ability | ≥28° | ||||||
| Fuel tank capacity | 3.5 L / 4.3 L | ||||||
| Headlight | Lens LED, high beam 15W / low beam 6W / position light 5W | ||||||
| Taillight | LED, running 5W / brake 10W / position 1.2W | ||||||
| Front indicators | Dynamic LED 0.6W / 1W | ||||||
| Rear indicators | Dynamic LED 0.8W / 1W | ||||||
| License plate light | 5 W | ||||||
| Battery | Maintenance-free, 6MF7EL gel battery | ||||||
Custom motorcycle orders accepted
