107cc Horizontal Engine Underbone Motorcycle with 4-Speed Semi-Automatic and Dual Start System
This 107cc horizontal single-cylinder motorcycle is built for stable daily commuting. It adopts air-cooled engine, CDI ignition and dual electric & kick start system, providing smooth power with 5.2kW max power and 7.2N·m max torque. Equipped with 4-speed semi-automatic clutch, telescopic hydraulic front fork and dual rear shock absorbers, it ensures comfortable and easy handling.
| Item | Description | |||||||
| Engine Type | Single-cylinder, horizontal engine | |||||||
| Bore × Stroke | 52.4 mm × 49.5 mm | |||||||
| Displacement | 107 cc | |||||||
| Compression Ratio | 9.1 : 1 | |||||||
| Max. Power | 5.2 kW @ 8,000 ± 500 rpm | |||||||
| Max. Torque | 7.2 N·m @ 5,000 ± 500 rpm | |||||||
| Ignition System | CDI ignition | |||||||
| Starting System | Electric & kick start | |||||||
| Magneto | 6-pole magneto, full-wave rectification | |||||||
| Transmission | 4-speed, semi-automatic clutch | |||||||
| Final Drive | Chain drive | |||||||
| Front Suspension | Telescopic hydraulic fork | |||||||
| Rear Suspension | Dual spring shock absorbers | |||||||
| Front Brake | Drum brake | |||||||
| Rear Brake | Drum brake | |||||||
| Front Tire | 2.50-17 | |||||||
| Rear Tire | 2.75-17 | |||||||
| Front Wheel | Spoked wheel / Optional: aluminum wheel | |||||||
| Rear Wheel | Spoked wheel / Optional: aluminum wheel | |||||||
| Rear Carrier | Yes | |||||||
| Center Carrier | Yes | |||||||
| Overall Dimensions (L×W×H) | 1900 × 700 × 1070 mm | |||||||
| Wheelbase | 1220 mm | |||||||
| Seat Height | 740 mm | |||||||
| Ground Clearance | 110 mm | |||||||
| Net Weight | 86 kg | |||||||
| Max. Load Capacity | 150 kg | |||||||
| Max. Speed | 80 km/h | |||||||
| Climbing Ability | ≥ 27° | |||||||
| Fuel Tank Capacity | 3.5 L | |||||||
| Helmet Box | No | |||||||
| Headlight | 12V 35W | |||||||
| Taillight | Combined taillight, 12V 21W / 10W | |||||||
| Front Turn Signals | 12V 5W | |||||||
| Rear Turn Signals | 12V 5W | |||||||
| License Plate Light | 12V 5W | |||||||
| Battery | 12V 5Ah, maintenance-free | |||||||
With front and rear drum brakes, durable spoke wheels, dual rear & center carrier, it delivers strong practicality. It reaches max speed 80km/h, climbing ability ≥27°, 3.5L fuel tank and 150kg max load. Compact size, low seat height and lightweight body make it ideal for city riding and daily transportation.
