125cc Enduro Motorcycle with 5.5kW Max Power, 7.5N·m Max Torque, and 27° Climbing Ability
The vehicle is fully equipped with suspension and safety configurations, ensuring comfortable and safe riding. Hydraulic front fork paired with twin rear shock absorber system can effectively buffer road bumps, cope with potholes, gravel and other complex road conditions, and greatly improve riding comfort. Front disc and rear drum brake (upgradeable) with sensitive and quick braking, timely avoiding driving risks; 200mm minimum ground clearance, paired with climbing ability ≥27°, easily crossing bumpy roads and steep slopes with excellent passability. 12V 5Ah maintenance-free gel battery, saving trouble and effort without frequent maintenance, with a built-in USB 2A charger, which can power mobile phones and other devices at any time, meeting the charging needs of outdoor travel, and the detailed design is very considerate.
| Specification | Details | |||||||
| Engine Type | 125cc, Air-Cooled, Single Cylinder | |||||||
| Bore × Stroke | 54 × 69 mm | |||||||
| Displacement | 125 cc | |||||||
| Compression Ratio | 9.1:1 | |||||||
| Max Power | 5.5 kW @ 8000 ± 500 rpm | |||||||
| Max Torque | 7.5 N·m @ 5000 ± 500 rpm | |||||||
| Ignition | CDI (Capacitor Discharge Ignition) | |||||||
| Starting System | Kick start & Electric start | |||||||
| Magneto | 6-pole, Full-wave AC | |||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | |||||||
| Transmission Mode | Chain drive | |||||||
| 1st Gear Ratio | 3.273 | |||||||
| 2nd Gear Ratio | 1.938 | |||||||
| 3rd Gear Ratio | 1.35 | |||||||
| 4th Gear Ratio | 1.043 | |||||||
| Primary / Final Drive Ratio | 3.722 / 2.714 | |||||||
| Front Suspension | Hydraulic Fork | |||||||
| Rear Suspension | Twin Shock Absorbers | |||||||
| Front Brake | Disc / Optional: Expandable Shoe / Drum | |||||||
| Rear Brake | Drum / Optional: Expandable Shoe | |||||||
| Front Tire | 2.50-17 | |||||||
| Rear Tire | 2.75-17 | |||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | |||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | |||||||
| Rear Shelf | Optional: Rubber-coated Rear Shelf / Large Shelf | |||||||
| Middle Shelf | Optional: Yes / Default: No | |||||||
| Length × Width × Height | 1940 × 700 × 1100 mm | |||||||
| Wheelbase | 1240 mm | |||||||
| Seat Height | 800 mm | |||||||
| Min Ground Clearance | 200 mm | |||||||
| Net Weight | 87 kg | |||||||
| Max Load | 150 kg | |||||||
| Max Speed | 90 km/h | |||||||
| Climbing Ability | ≥27° | |||||||
| Fuel Tank Capacity | 3 L | |||||||
| Helmet Box Capacity | Fits half helmet / half-face helmet | |||||||
| Headlight | 12V 35W Standard / Optional LED 12V 8W | |||||||
| Taillight | LED 1.2W (Brake Light) / 1.2W (Position Light), Standard 21W / 5W | |||||||
| Front Indicators | Standard 10W / LED 0.8W | |||||||
| Rear Indicators | Standard 10W / LED 0.8W | |||||||
| Logo Light | Standard 0.3W | |||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | |||||||
| Charger | USB 2A | |||||||
