125cc Lightweight Motorcycle with 87kg Net Weight 800mm Seat Height and 3L Fuel Tank for Easy Commuting
Humanized design balances convenience and practicality, adapting to the needs of different groups of people. The body size is 1940×700×1100mm, with a net weight of 87kg for easy handling, and the 800mm seat height is suitable for most male and female riders, easy to get started. The 3L fuel tank meets daily commuting endurance, and the helmet box can hold a half helmet for convenient storage; multiple configurations such as wheels and shelves are optional, and you can upgrade to rubber-coated rear shelf, large shelf or aluminum wheels according to needs, meeting the needs of carrying people and goods, with a maximum load capacity of 150kg, full of practicality. The LED lighting system is bright enough for clear vision during night riding, multiple colors adapt to different aesthetics, with outstanding cost performance, making it an excellent choice for home commuting and short-distance travel.
| Specification | Details | |||||||
| Engine Type | 125cc, Air-Cooled, Single Cylinder | |||||||
| Bore × Stroke | 54 × 69 mm | |||||||
| Displacement | 125 cc | |||||||
| Compression Ratio | 9.1:1 | |||||||
| Max Power | 5.5 kW @ 8000 ± 500 rpm | |||||||
| Max Torque | 7.5 N·m @ 5000 ± 500 rpm | |||||||
| Ignition | CDI (Capacitor Discharge Ignition) | |||||||
| Starting System | Kick start & Electric start | |||||||
| Magneto | 6-pole, Full-wave AC | |||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | |||||||
| Transmission Mode | Chain drive | |||||||
| 1st Gear Ratio | 3.273 | |||||||
| 2nd Gear Ratio | 1.938 | |||||||
| 3rd Gear Ratio | 1.35 | |||||||
| 4th Gear Ratio | 1.043 | |||||||
| Primary / Final Drive Ratio | 3.722 / 2.714 | |||||||
| Front Suspension | Hydraulic Fork | |||||||
| Rear Suspension | Twin Shock Absorbers | |||||||
| Front Brake | Disc / Optional: Expandable Shoe / Drum | |||||||
| Rear Brake | Drum / Optional: Expandable Shoe | |||||||
| Front Tire | 2.50-17 | |||||||
| Rear Tire | 2.75-17 | |||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | |||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | |||||||
| Rear Shelf | Optional: Rubber-coated Rear Shelf / Large Shelf | |||||||
| Middle Shelf | Optional: Yes / Default: No | |||||||
| Length × Width × Height | 1940 × 700 × 1100 mm | |||||||
| Wheelbase | 1240 mm | |||||||
| Seat Height | 800 mm | |||||||
| Min Ground Clearance | 200 mm | |||||||
| Net Weight | 87 kg | |||||||
| Max Load | 150 kg | |||||||
| Max Speed | 90 km/h | |||||||
| Climbing Ability | ≥27° | |||||||
| Fuel Tank Capacity | 3 L | |||||||
| Helmet Box Capacity | Fits half helmet / half-face helmet | |||||||
| Headlight | 12V 35W Standard / Optional LED 12V 8W | |||||||
| Taillight | LED 1.2W (Brake Light) / 1.2W (Position Light), Standard 21W / 5W | |||||||
| Front Indicators | Standard 10W / LED 0.8W | |||||||
| Rear Indicators | Standard 10W / LED 0.8W | |||||||
| Logo Light | Standard 0.3W | |||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | |||||||
| Charger | USB 2A | |||||||
