97cc Single-Cylinder Horizontal Underbone Motorcycle with Electric & Kick Dual Start and 4-Speed Automatic Clutch
This 97cc single-cylinder horizontal motorcycle focuses on practicality, suitable for various scenarios such as daily commuting and short-distance travel, balancing performance and convenience. Equipped with a 97cc single-cylinder horizontal engine, 9.1:1 compression ratio, maximum power 4.5kW and maximum torque 6.5N·m, it delivers stable power output. Paired with EFI electronic fuel injection + CDI ignition, it has excellent fuel economy, quick and stable starting. The electric & kick dual-start design ensures easy starting in complex environments.
| Engine Specification Details Table | |||||||
| Specification | Details | ||||||
| Engine Type & Cylinder Arrangement | Single-cylinder, horizontal | ||||||
| Displacement | 97 cc | ||||||
| Bore × Stroke | 50 × 49.5 mm | ||||||
| Compression Ratio | 9.1:1 | ||||||
| Max Power | 4.5 kW @ 8000 ± 500 rpm | ||||||
| Max Torque | 6.5 N·m @ 6000 ± 500 rpm | ||||||
| Ignition | Electronic Fuel Injection (EFI), CDI | ||||||
| Starting System | Kick & Electric Start | ||||||
| Magneto | 12-pole DC | ||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | ||||||
| Transmission Mode | Chain drive | ||||||
| 1st Gear Ratio | 3.273 | ||||||
| 2nd Gear Ratio | 1.938 | ||||||
| 3rd Gear Ratio | 1.35 | ||||||
| 4th Gear Ratio | 1.043 | ||||||
| Primary / Final Drive Ratio | 4.059 / 2.714 | ||||||
| Front Suspension | Hydraulic Fork | ||||||
| Rear Suspension | Twin Shock Absorbers | ||||||
| Front Brake | Disc | ||||||
| Rear Brake | Drum / Expandable Shoe | ||||||
| Front Tire | 2.50-16, Standard / Optional: Deep Tread Tire | ||||||
| Rear Tire | 2.75-16, Standard / Optional: Deep Tread Tire | ||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Carrier | Optional: Rear Shelf / Large Shelf | ||||||
| Middle Shelf | Optional: Yes / Default: No | ||||||
| Overall Length × Width × Height | 1860 × 700 × 1270 mm | ||||||
| Wheelbase | 1220 mm | ||||||
| Seat Height | 780 mm | ||||||
| Min Ground Clearance | 130 mm | ||||||
| Net Weight | 90 kg | ||||||
| Max Load | 150 kg | ||||||
| Max Speed | 75 km/h | ||||||
| Climbing Ability | ≥12° | ||||||
| Fuel Tank Capacity | 3.1 L | ||||||
| Helmet Box Capacity | Fits Full Helmet | ||||||
| Headlight | LED Lens, Low Beam 8W / High Beam 12W | ||||||
| Taillight | LED 1.2W (Brake) / 1.2W (Position), Standard 21W / 5W | ||||||
| Front Indicators | Standard 10W / LED 0.8W | ||||||
| Rear Indicators | Standard 10W / LED 0.8W | ||||||
| Logo Light | Standard 0.3W | ||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | ||||||
| Charger | USB 2A | ||||||
4-speed automatic clutch gearbox with high gear protection, simple and easy to operate, suitable for both men and women; chain drive mode with reasonable gear ratio ensures smooth driving, maximum speed up to 75km/h, climbing ability ≥12°, easily coping with daily road conditions. The suspension system adopts hydraulic front fork + twin rear shock absorbers, effectively buffering road bumps for a full riding comfort; front disc and rear drum brakes with sensitive braking ensure riding safety.
