China 107cc Air-Cooled Underbone Motorcycle with 150kg Load Capacity and 4-Speed Automatic Clutch for Enduro and Commuting for sale

107cc Air-Cooled Underbone Motorcycle with 150kg Load Capacity and 4-Speed Automatic Clutch for Enduro and Commuting

Price Negotiable

Price: Price negotiable

MOQ: 100

Delivery Time: 5-12 weeks

Brand: ZFYC

Product Description

125cc air-cooled single cylinder engine with 9.1:1 compression ratio, 5.5kW max power and 7.5N·m peak torque, ensuring brisk start and strong climbing performance, easily handling complex road conditions with ≥27° climbing ability. 4-speed automatic clutch with high gear protection, friendly for beginners; kick start & electric start dual modes, no fear of low temperature or battery depletion, more worry-free for daily commuting.

Specification		Details
Engine Type		125cc, Air-Cooled, Single Cylinder
Bore × Stroke		54 × 69 mm
Displacement		107 cc
Compression Ratio		9.1:1
Max Power		5.5 kW @ 8000 ± 500 rpm
Max Torque		7.5 N·m @ 5000 ± 500 rpm
Ignition		CDI (Capacitor Discharge Ignition)
Starting System		Kick start & Electric start
Magneto		6-pole, Full-wave AC
Gear & Clutch		4-speed, Automatic Clutch (with high gear protection)
Transmission Mode		Chain drive
1st Gear Ratio		3.273
2nd Gear Ratio		1.938
3rd Gear Ratio		1.35
4th Gear Ratio		1.043
Primary / Final Drive Ratio		3.722 / 2.714
Front Suspension		Hydraulic Fork
Rear Suspension		Twin Shock Absorbers
Front Brake		Disc / Optional: Expandable Shoe / Drum
Rear Brake		Drum / Optional: Expandable Shoe
Front Tire		2.50-17
Rear Tire		2.75-17
Front Wheel		Spoked / Optional: Aluminum Wheel
Rear Wheel		Spoked / Optional: Aluminum Wheel
Rear Shelf		Optional: Rubber-coated Rear Shelf / Large Shelf
Middle Shelf		Optional: Yes / Default: No
Length × Width × Height		1940 × 700 × 1100 mm
Wheelbase		1240 mm
Seat Height		800 mm
Min Ground Clearance		200 mm
Net Weight		87 kg
Max Load		150 kg
Max Speed		90 km/h
Climbing Ability		≥27°
Fuel Tank Capacity		3 L
Helmet Box Capacity		Fits half helmet / half-face helmet
Headlight		12V 35W Standard / Optional LED 12V 8W
Taillight		LED 1.2W (Brake Light) / 1.2W (Position Light), Standard 21W / 5W
Front Indicators		Standard 10W / LED 0.8W
Rear Indicators		Standard 10W / LED 0.8W
Logo Light		Standard 0.3W
Battery		12V 5Ah, Maintenance-Free Gel Battery
Charger		USB 2A
