ZF110-10 107cc Air-Cooled Underbone Motorcycle with 4-Speed Automatic Clutch and Dual Start System
Price:
Price negotiable
MOQ:
100
Delivery Time:
5-12 weeks
Brand:
ZFYC
Product Description
The ZF110-10 is equipped with a 107cc air-cooled engine, CDI ignition, and kick & electric start for convenience. It features a 4-speed automatic clutch with high gear protection for easy operation. Hydraulic front fork and twin rear absorbers ensure a smooth ride; front disc and rear drum brakes deliver reliable safety. With 17-inch tubeless tires, LED lights, and USB charging, it’s practical and versatile. Lightweight body, 770mm seat height, 3.1L fuel tank, 75km/h max speed, and ≥12° climbing ability, ideal for commuting and cargo carrying.
| Specification | Details | ||||||
| Model No | ZF110-10 | ||||||
| Engine Type | Air-Cooled, Single Cylinder | ||||||
| Bore × Stroke | 52.4 × 49.5 mm | ||||||
| Displacement | 107cm³ | ||||||
| Compression Ratio | 9.1:1 | ||||||
| Max Power | 5.2 kW @ 8000 ± 500 rpm | ||||||
| Max Torque | 7.2 N·m @ 5000 ± 500 rpm | ||||||
| Ignition | CDI (Capacitor Discharge Ignition) | ||||||
| Starting System | Kick start & Electric start | ||||||
| Magneto | 12V, 8-pole, Full-wave AC | ||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | ||||||
| Transmission Mode | Chain drive | ||||||
| 1st Gear Ratio | 3.273 | ||||||
| 2nd Gear Ratio | 1.938 | ||||||
| 3rd Gear Ratio | 1.35 | ||||||
| 4th Gear Ratio | 1.043 | ||||||
| Primary Drive Ratio | 4.059 / 2.714 | ||||||
| Front Suspension | Hydraulic Fork | ||||||
| Rear Suspension | Twin Shock Absorbers | ||||||
| Front Brake | Disc / Optional: Expandable Shoe / Drum | ||||||
| Rear Brake | Drum / Optional: Expandable Shoe | ||||||
| Front Tire | 2.50-17, Tubeless / Optional: Deep Tread Tires | ||||||
| Rear Tire | 2.75-17, Tubeless / Optional: Deep Tread Tires | ||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Shelf | Optional: Rear Shelf / Large Shelf | ||||||
| Middle Shelf | Optional: Yes / Default: No | ||||||
| Length × Width × Height | 1940 × 720 × 1130 mm | ||||||
| Wheelbase | 1250 mm | ||||||
| Seat Height | 770 mm | ||||||
| Min Ground Clearance | 150 mm | ||||||
| Net Weight | 95 kg | ||||||
| Max Load | 150 kg | ||||||
| Max Speed | 75 km/h | ||||||
| Climbing Ability | ≥ 12° | ||||||
| Fuel Tank Capacity | 3.1 L | ||||||
| Helmet Box Capacity | Fits full helmet | ||||||
| Headlight | LED Lens, 12V 8W (Low Beam) / 12W (High Beam) | ||||||
| Taillight | LED 1.2W (Brake Light) / 1.2W (Position Light), Standard 21W / 5W | ||||||
| Front Indicators | Standard 10W / LED 0.8W | ||||||
| Rear Indicators | Standard 10W / LED 0.8W | ||||||
| Logo Light | Standard 0.3W | ||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | ||||||
| Charger | USB 2A | ||||||
Custom motorcycle orders accepted
Wholesale from Factory
