60V PMSM Electric Motorcycle with 4.8KW Peak Power 166N・m Torque and Removable Battery for Long Range Commuting
Price:
Price negotiable
MOQ:
100
Delivery Time:
5-12 weeks
Brand:
ZFYC
Product Description
Equipped with a permanent magnet synchronous motor, rated 1.5KW, peak 4.8KW, 166N·m high torque, with FOC vector control for smooth and strong power, easily climbing ≥25° slopes. It comes with 60V removable LiFePO4/NMC batteries: 30Ah version offers 60-95KM range, 50Ah version up to 100-158KM. Front disc rear drum brake, LED speedometer and lights, lightweight design (80.5kg kerb weight), 1265mm wheelbase, 160mm ground clearance, 150kg max load, ideal for urban commuting and short trips.
| Motor Type | Permanent Magnet Synchronous Motor |
| Rated Power | 1.5KW |
| Peak Power | 4.8KW |
| Maximum Torque | 166N·m |
| Transmission | Chain Drive |
| Mode | P Gear |
| Communication | CAN Communication |
| Controller | FOC Vector Controller |
| Speedometer | LED Speedometer |
| Rated Voltage | 60V |
| Dimensions (L×W×H) | 1960 × 710 × 1200 mm |
| Wheelbase | 1265 mm |
| Ground Clearance | 160 mm |
| Seat Height | 750 mm |
| Wheels (Front/Rear) | Front Tire: 2.50-17 |
| Rear Tire: 2.75-17 | |
| Maximum Speed | 45km/h |
| Maximum Gradeability | ≥25° |
| Braking System | Front: Disc Brake / Rear: Drum Brake |
| Battery | Removable Lithium Battery Pack |
| • 60V 30Ah (LFP) | |
| • 60V 50Ah (Ternary Lithium Battery) | |
| Lighting | LED |
| Kerb Weight | 80.5 kg (without battery) |
| Gross Weight | 92.5 kg (with 60V 30Ah battery) |
| Maximum Load | 150 kg |
Custom motorcycle orders accepted
Wholesale from Factory
Wholesale from Factory
