ZF110-10 107cc Underbone Motorcycle with 4-Speed Automatic Clutch and Electric & Kick Start for Urban Commuting
ZF110-10 is a practical motorcycle designed for daily commuting and family use. It is powered by a 107cc single-cylinder air-cooled engine with smooth and economical power output, delivering 5.2kW maximum power and 7.2N·m maximum torque. With a reasonable 9.1:1 compression ratio, it balances performance and fuel efficiency perfectly. Equipped with a reliable CDI ignition system, it provides accurate and stable ignition. The dual electric and kick start system ensures easy starting in all conditions for greater peace of mind. The 4-speed automatic clutch with high gear protection is simple to operate without manual clutch control, making it friendly for beginners. Precisely tuned gear and drive ratios deliver brisk starting and smooth running, ideal for daily commuting.
| Specification | Details | ||||||
| Model No | ZF110-10 | ||||||
| Engine Type | Air-Cooled, Single Cylinder | ||||||
| Bore × Stroke | 52.4 × 49.5 mm | ||||||
| Displacement | 107cm³ | ||||||
| Compression Ratio | 9.1:1 | ||||||
| Max Power | 5.2 kW @ 8000 ± 500 rpm | ||||||
| Max Torque | 7.2 N·m @ 5000 ± 500 rpm | ||||||
| Ignition | CDI (Capacitor Discharge Ignition) | ||||||
| Starting System | Kick start & Electric start | ||||||
| Magneto | 12V, 8-pole, Full-wave AC | ||||||
| Gear & Clutch | 4-speed, Automatic Clutch (with high gear protection) | ||||||
| Transmission Mode | Chain drive | ||||||
| 1st Gear Ratio | 3.273 | ||||||
| 2nd Gear Ratio | 1.938 | ||||||
| 3rd Gear Ratio | 1.35 | ||||||
| 4th Gear Ratio | 1.043 | ||||||
| Primary Drive Ratio | 4.059 / 2.714 | ||||||
| Front Suspension | Hydraulic Fork | ||||||
| Rear Suspension | Twin Shock Absorbers | ||||||
| Front Brake | Disc / Optional: Expandable Shoe / Drum | ||||||
| Rear Brake | Drum / Optional: Expandable Shoe | ||||||
| Front Tire | 2.50-17, Tubeless / Optional: Deep Tread Tires | ||||||
| Rear Tire | 2.75-17, Tubeless / Optional: Deep Tread Tires | ||||||
| Front Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Wheel | Spoked / Optional: Aluminum Wheel | ||||||
| Rear Shelf | Optional: Rear Shelf / Large Shelf | ||||||
| Middle Shelf | Optional: Yes / Default: No | ||||||
| Length × Width × Height | 1940 × 720 × 1130 mm | ||||||
| Wheelbase | 1250 mm | ||||||
| Seat Height | 770 mm | ||||||
| Min Ground Clearance | 150 mm | ||||||
| Net Weight | 95 kg | ||||||
| Max Load | 150 kg | ||||||
| Max Speed | 75 km/h | ||||||
| Climbing Ability | ≥ 12° | ||||||
| Fuel Tank Capacity | 3.1 L | ||||||
| Helmet Box Capacity | Fits full helmet | ||||||
| Headlight | LED Lens, 12V 8W (Low Beam) / 12W (High Beam) | ||||||
| Taillight | LED 1.2W (Brake Light) / 1.2W (Position Light), Standard 21W / 5W | ||||||
| Front Indicators | Standard 10W / LED 0.8W | ||||||
| Rear Indicators | Standard 10W / LED 0.8W | ||||||
| Logo Light | Standard 0.3W | ||||||
| Battery | 12V 5Ah, Maintenance-Free Gel Battery | ||||||
| Charger | USB 2A | ||||||
The front hydraulic telescopic fork and twin rear shock absorbers effectively absorb road bumps for enhanced riding comfort. The front disc and rear drum brake system offers sensitive and stable braking to ensure travel safety. The motorcycle comes standard with spoked wheels, and aluminum wheels are optional. Tires are available in tubeless or deep tread versions to adapt to different road conditions. With dimensions of 1940×720×1130mm and a 1250mm wheelbase, it features a user-friendly 770mm seat height and 150mm ground clearance for decent passability. At 95kg net weight, it is lightweight and easy to handle, while the 150kg max load meets daily passenger and cargo needs.
The 3.1L fuel tank provides excellent fuel economy, and the helmet box can accommodate a full-face helmet for great practicality. It is equipped with an LED lens headlight for brighter and more energy-efficient lighting. Turn signals and taillights are available in LED versions, paired with a 12V 5Ah maintenance-free gel battery for longer service life. A built-in 2A USB charger supports emergency device charging. Rear and middle shelves are optional for added versatility. Durable, easy to maintain and low in failure rate, ZF110-10 is a cost-effective, reliable and practical choice for urban commuting, short-distance travel and daily family use.
