Cost-effective 107cc Engine Underbone Motorcycle with 150kg Load Capacity and 78km/h Max Speed for Daily Commuting

Price Negotiable
Price: Price negotiable
MOQ: 100
Delivery Time: 5-12 weeks
Brand: ZFYC
Product Description

This practical 107cc air-cooled motorcycle integrates reliable performance and daily usability. The horizontal engine features compact structure and stable operation, with 9.1:1 compression ratio balancing power and fuel economy, ideal for long-term family use. The 12V 8-pole full-wave magneto provides stable power supply, and the maintenance-free battery saves frequent maintenance trouble. With overall dimensions 1920×720×1140mm and 1255mm wheelbase, it runs smoothly without being bulky. The maximum speed reaches 78km/h to meet urban road demands. Front and rear tires with special tread patterns offer strong grip to adapt to various road conditions. The compact and agile body makes it easy to maneuver, park and travel through traffic. At 93kg curb weight, it is easy to handle even for women and new riders. The 780mm seat height fits most people, reducing fatigue during long rides. 150kg max load, aluminum rear carrier and helmet storage greatly improve practicality, perfect for daily errands, family pickup and short-distance travel. Halogen lights satisfy night riding needs, with well-balanced braking and suspension configuration. Durable, fuel-efficient and low in failure rate, it is a national-level commuter motorcycle with excellent quality, practicality and cost performance.

Item Specification
Engine Type Single-cylinder, horizontal, air-cooled
Bore × Stroke 52.4 mm × 49.5 mm
Displacement 107 cc
Compression Ratio 9.1 : 1
Max. Power 5.2 kW @ 8,000 ± 500 rpm
Max. Torque 7.2 N·m @ 5,000 ± 500 rpm
Ignition System CDI
Starting System Electric & kick start
Magneto 12V, 8-pole, full-wave AC
Transmission 4-speed, semi-automatic clutch
Final Drive Chain drive
Primary Reduction Ratio 4.059
Final Reduction Ratio 2.714
1st Gear 3.273
2nd Gear 1.938
3rd Gear 1.35
4th Gear 1.043
Front Suspension Telescopic hydraulic fork
Rear Suspension Dual shock absorbers
Front Brake Drum brake
Rear Brake Drum brake
Front Tire 2.50-17 (M031 tread pattern)
Rear Tire 2.75-16 (M034 tread pattern)
Front Wheel Aluminum wheel
Rear Wheel Aluminum wheel
Rear Carrier Aluminum rear carrier
Center Carrier Equipped
Overall Dimensions (L × W × H) 1920 × 720 × 1140 mm
Wheelbase 1255 mm
Seat Height 780 mm
Ground Clearance 140 mm
Net Weight 93 kg
Max. Load Capacity 150 kg
Max. Speed 78 km/h
Climbing Ability ≥ 22°
Fuel Tank Capacity 3.1 L
Helmet Box Capacity Half-face helmet
Headlight Halogen bulb, 12V 35W (low beam 5W / high beam 12W)
Taillight Halogen bulb, 12V 21W / 5W
Front Turn Signals Halogen, 12V 10W
Rear Turn Signals Halogen, 12V 10W
License Plate Light 12V 5W
Battery 12V 5Ah, maintenance-free


Custom motorcycle orders accepted
