107cc EFI Underbone Motorcycle with 4-Speed Semi-Auto Clutch and 150kg Load Capacity
This 107cc horizontal single‑cylinder air‑cooled motorcycle adopts EFI fuel injection system, delivering stable power with 4.5kW max power and 6.5N·m torque, fuel‑saving and high‑efficiency. Equipped with 4‑speed semi‑auto clutch and chain drive, it shifts smoothly for various road conditions. Dual electric & kick start with CDI ignition ensures easy startup.
Telescopic hydraulic front fork and dual rear shocks bring comfortable ride. Front & rear drum brakes offer stable braking, with optional deep‑tread tires and steel rims for strong grip. 750mm low seat height and 94.4kg lightweight body support max 150kg load for commuting and cargo use.
3.1L fuel tank ensures long endurance. LED lights, dynamic turn signals and 2A USB charger are equipped. Helmet box fits full‑face helmet, maintenance‑free gel battery provides stable power. Max speed 75km/h and great climbing ability, ideal for urban‑rural travel and short‑haul cargo transport.
| Item | Specification | ||||||
| Engine Type | Single-cylinder, horizontal, air-cooled | ||||||
| Bore × Stroke | 52.4 mm × 49.5 mm | ||||||
| Displacement | 107 cc | ||||||
| Compression Ratio | 9.1 : 1 | ||||||
| Max. Power | 4.5 kW @ 8,000 rpm | ||||||
| Max. Torque | 6.5 N·m @ 6,000 rpm | ||||||
| Fuel System | Electronic Fuel Injection (EFI) | ||||||
| Ignition System | CDI | ||||||
| Starting System | Electric & kick start | ||||||
| Magneto | 12-pole DC | ||||||
| Transmission | 4-speed, semi-automatic clutch | ||||||
| Final Drive | Chain drive | ||||||
| Primary / Final Reduction Ratio | 4.059 / 2.714 | ||||||
| 1st Gear | 3.273 | ||||||
| 2nd Gear | 1.938 | ||||||
| 3rd Gear | 1.35 | ||||||
| 4th Gear | 1.043 | ||||||
| Front Suspension | Telescopic hydraulic fork | ||||||
| Rear Suspension | Dual shock absorbers | ||||||
| Front Brake | Drum brake | ||||||
| Rear Brake | Drum brake | ||||||
| Front Tire | 2.50-16 (standard tire / optional deep tread tire) | ||||||
| Rear Tire | 2.75-16 (standard tire / optional deep tread tire) | ||||||
| Front Wheel | Spoked wheel (optional steel rim) | ||||||
| Rear Wheel | Spoked wheel (optional steel rim) | ||||||
| Rear Carrier | Optional rear carrier / large rear carrier | ||||||
| Center Carrier | Optional | ||||||
| Overall Dimensions (L × W × H) | 1860 × 810 × 1250 mm | ||||||
| Wheelbase | 1200 mm | ||||||
| Seat Height | 750 mm | ||||||
| Ground Clearance | 110 mm | ||||||
| Net Weight | 94.4 kg | ||||||
| Max. Load Capacity | 150 kg | ||||||
| Max. Speed | 75 km/h | ||||||
| Climbing Ability | ≥ 12° | ||||||
| Fuel Tank Capacity | 3.1 L | ||||||
| Helmet Box Capacity | Full-face helmet | ||||||
| Headlight | LED, 12V 8W (low beam) / 12W (high beam) | ||||||
| Taillight | LED 1.2W (brake) / 1.2W (position) | ||||||
| Front Turn Signals | Dynamic indicator, halogen 10W / LED 0.8W | ||||||
| Rear Turn Signals | Dynamic indicator, halogen 10W / LED 0.8W | ||||||
| Logo Light | 0.3W | ||||||
| Battery | 12V 5Ah, maintenance-free gel battery | ||||||
| USB Charger | USB, 2A | ||||||
Custom motorcycle orders accepted
Wholesale from Factory
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
