The 5/8" System 16mm Welding Fit-up Table with Steel Legs is an industrial-grade precision welding fixture designed for the European and American markets. Its core design is based on a 16mm (equivalent to 5/8" imperial) bore diameter + 50mm (2-inch) mesh hole system, paired with steel support legs.
| Hole System | Hole diameter 16mm (5/8 inch), grid spacing 50mm (2 inch), five-sided (top + four side) perforation, hole position tolerance ±0.02mm |
|---|---|
| Countertop configuration | Material: Q355 low-alloy high-strength steel / hardened tool steel Thickness: 12–16mm Surface treatment: Nitriding / quenching (hardness 45–50HRC), anti-weld slag, rust prevention |
| Steel support legs | Material: Welded square tubing frame Feet: Self-leveling (adjustment range ±50mm) Single leg load capacity: ≥1.5 tons, overall load capacity: 3–7 tons (depending on table size) |
| Standard size | Tabletop: 500×1000/1000×1500/2000×1500mm Overall height: 620mm (including legs) Customizable to 4000×2000mm |
| Precision Standard | Flatness: ≤ ±0.0127mm per 600×600mm Repeatability: ±0.08mm |
Detailed design: Balancing practicality and durability
1. Hole Protection Design: Dustproof rubber plugs are pre-installed at the table holes to prevent welding slag and metal filings from entering during transportation and storage, avoiding wear on the hole walls that could affect positioning accuracy. These plugs can be quickly removed before use, ensuring efficient tooling assembly.
2. Tabletop Edge Treatment: The tabletop edges are rounded to prevent sharp corners from scratching operators or workpieces, meeting the "Industrial Equipment Safety Protection" requirements of the EU CE safety standard.
3. Quick-Assemble Support Legs: The steel legs are connected to the tabletop with quick-release bolts. A single unit can be disassembled/assembled within 10 minutes, facilitating workstation transfers within the customer's workshop or saving packaging space during long-distance sea freight.
Usage Costs: A Long-Term Advantage for Cost Reduction and Efficiency Improvement
1. Efficient Tooling Changeover: Modular fixtures and standardized hole systems reduce tooling setup time from 30-60 minutes on traditional welding tables to 5-10 minutes. For small-batch production, this can save over 100 hours of auxiliary labor per month.
2. Low Maintenance Costs:The table surface is hardened to 45-50 HRC, making it wear-resistant and resistant to weld slag impact. Under normal use, the table surface does not need replacement for 5 years. Hole cleaning only requires compressed air blowing, eliminating the need for specialized maintenance tools.
3. High Residual Value:The steel body and standardized hole system design allow the equipment to be disassembled and recycled as steel after obsolescence, or resold as second-hand equipment. The residual value is over 30% higher than non-standardized welding tables.
