14mm 18mm machining fixture clamps Insert Ratcheting modular F Clamp for Workshop

Price Negotiable

Price: 1-100 USD

MOQ: 1

Delivery Time: 7-10 work days

Brand: LEMAR

Product Description

Industrial Grade Insert Ratcheting F Clamp for Workshop Use

This industrial-grade F clamp is engineered for high durability and versatility in demanding workshop environments. Designed for high-intensity, high-frequency operations, it delivers strong clamping force, exceptional wear resistance, and straightforward maintenance. Ideal for machining, sheet metal grinding, parts assembly, and woodworking applications.

Technical Specifications

Specification	Details
Clamp Arm Material	Q345B Low-Alloy High-Strength Steel
Surface Treatment	Blackening and Rust Prevention / Electrogalvanizing / Powder Coating
Ratchet Gear Module	2.0mm
Lead Screw Specifications	Diameter: 16mm/20mm/24mm/28mm; Pitch: 3.0mm
Maximum Clamping Force	15kN/20kN/25kN/30kN
Jaw Width	50mm/60mm/80mm

Industrial Grade Insert Ratcheting F Clamp in workshop environment

Technical diagram of Industrial Grade Insert Ratcheting F Clamp components

Core Advantages

Ultra-High Durability: Constructed from low-alloy steel with reinforced components, withstands rough workshop handling including collisions and drops. Service life exceeds 8 years - three times longer than ordinary workshop clamps.
Strong Clamping Force Output: Maximum clamping force reaches 30kN (3 tons), easily securing heavy metal plates, thick-walled pipes, large wood pieces, and other workpieces for heavy-duty operations.
Multi-Purpose Functionality: Three-in-one detachable pads with dual-mode bottom structure adapt to various workshop processes including metal processing, woodworking, and assembly, reducing clamp variety requirements.
Easy Maintenance: Ratchet mechanism, lead screw, pads, and other core components can be individually disassembled and replaced, lowering maintenance costs and eliminating complete replacement needs.
Convenient Operation: Ergonomic ratchet wrench design provides comfortable grip, preventing fatigue during prolonged use and improving workshop efficiency.

Procurement Advantages

Cost-Effective: Factory-direct pricing 40% lower than comparable imported clamps. Service life up to 8 years with annual operating cost only one-third of ordinary clamps.
Flexible Procurement: Supports mixed batch purchasing with different models/specifications combinable. Minimum order quantity of 1 unit meets small-batch workshop replenishment needs.
Fast Delivery: Standard models in stock and shipped within 24 hours. Non-standard customized models delivered within 15-20 days without affecting production schedules.

Workshop Utilization and Return on Investment

Cost Reduction: Multi-functional design reduces fixture variety, lowering procurement costs by 30%. Replaceable core components avoid complete fixture scrapping, reducing maintenance costs by 50%.
Increased Efficiency: Fast adjustment with tool-free pad replacement reduces clamping time from 3 minutes to 30 seconds per workpiece, increasing batch processing efficiency by 5 times.
Enhanced Safety: Industrial-grade material strength prevents workpiece falling risks due to fixture breakage, reducing workshop safety incident rates.
