300kg Electric Tilting Welding Positioner, Industrial Rotary Welding Table
Price:
500-1000USD
MOQ:
1
Delivery Time:
10-20 work days
Brand:
LEMAR
Product Description
300kg Electric Tilting Welding Positioner, Industrial Rotary Welding Table
Product Overview
Application: Designed for medium-sized cylinders, pressure vessels and thick metal parts, widely used in metal processing and container production workshops.
Core Function: Combines electric angle adjustment and continuous 360° rotation, delivering steady load capacity and reliable running performance.
Operation Advantage: Electric tilting replaces manual adjustment, effectively reducing labor intensity and simplifying daily operation.
Processing Effect: Ensures consistent welding quality for circumferential seams, longitudinal seams and surface finishing, suitable for long-term continuous production.
Main Technical Parameters
| Item | Standard Specification | Optional Specification |
|---|---|---|
| Rated Horizontal Load | 300 kg | - |
| Rated 90° Tilt Load | 160 kg | - |
| Working Table Diameter | 450 mm | Custom size available |
| Tilting Mode | Electric driven adjustment | - |
| Tilting Range | 0° ~ 90° | - |
| Rotation Speed | 0.8 ~ 12 rpm, stepless adjustable | Custom speed range |
| Main Motor Power | DC 200W | - |
| Tilting Motor Power | 150W | - |
| Power Supply | AC 380V, 3 Phase, 50/60Hz | AC 415V / 440V |
| Overall Dimension (L×W×H) | 520×500×480 mm | - |
| Net Weight | 92 kg | - |
| Table Flatness | ≤ 0.12 mm/m | - |
| Control Mode | Wired control box + Foot pedal | Wireless remote controller |
Electric Drive System Advantages
- Drive Configuration: Separate dedicated motors for rotation and tilting, delivering steady power and quick response.
- Angle Adjustment: Enables smooth angle transition across the full 0° to 90° range.
- Safety Design: Built-in overload protection prevents parts damage from incorrect operation.
- Efficiency Upgrade: Outperforms manual models and works perfectly for frequent angle adjustment tasks.
Frame & Tabletop Craftsmanship
- Main Frame: Integrated welded structure with stress relief treatment for high rigidity and stable performance.
- Table Surface: Treated by quenching process, resistant to scratches and welding slag for extended service life.
- Positioning Precision: Strictly controlled surface flatness ensures accurate workpiece positioning for repeated industrial welding.
Delivery Inspection & Quality Assurance
- Pre-delivery Tests: Undergoes full-load operation, electric tilting and rotation stability tests strictly.
- Component Standard: All electric parts conform to relevant industrial safety regulations.
- Supporting Documents: Complete operation manuals and technical files are provided together.
- After-sales Service: 12-month standard warranty, plus lifelong technical support and spare parts supply.
Common Questions & Answers
Q: What is the rated load of this positioner?
A: The rated horizontal load is 300kg, and the bearing capacity at 90° tilting is 160kg, for medium-sized industrial workpieces.
Q: Is the tilting function electrically driven?
A: Yes. This is an electric tilting welding positioner, all angle adjustments are completed by motor drive.
Q: Can the rotation speed be adjusted?
A: It supports stepless speed regulation within 0.8~12 rpm, and customized speed range is acceptable.
Q: What power supply does the equipment use?
A: Standard 380V three-phase power, 415V/440V version can be customized for different regions.
Q: What after-sales support can you provide?
A: We provide 12-month full machine warranty, as well as lifelong technical support and spare parts supply.
