Precision 3D Modular Welding Fixture Table D16 For Small Metal Fabrication

The Precision 3D Modular Welding Fixture Table D16 is engineered specifically for small metal fabrication and precision assembly work. Built with high-strength Q355 steel and finished with professional nitriding treatment, this table delivers micron-level accuracy, exceptional durability, and unmatched versatility for delicate welding projects.

Using the standard 16mm hole system and a dense 50×50mm grid layout, the fine grid spacing enables millimeter-level adjustment and complex clamping solutions - making it an ideal workbench for processing small metal parts, thin sheet metals, and precision components.

• Ultra-High Precision D16 Hole System

  Industry-standard 16mm fixture holes on a dense 50×50mm grid with ± 0.05mm positioning accuracy. The fine pitch allows micron-level alignment for small and complex workpieces — no offset calculations, no guesswork, just precise clamping every time.

• Premium Nitrided Surface Treatment

  Professional nitriding creates a hard, protective layer with HV 550-650 hardness and 0.25-0.35mm depth. Benefits include:

  • Excellent resistance to welding spatter adhesion
  • Superior corrosion and scratch resistance
  • 5-10× longer service life than untreated steel
  • Easy cleanup and minimal maintenance
• Five-Sided CNC Machined Flatness

  Full CNC finishing on all 5 working surfaces (1 top + 4 sides) with ≤ 0.1mm/m flatness tolerance. Engraved grid lines and perimeter millimeter scales enable instant visual alignment — speeding up setup and eliminating measurement errors.

• 3D Modular Versatility

  Supports horizontal, vertical, and angled fixturing for complete 3D build capability. Fully compatible with all major D16 fixturing accessories: clamps, stop blocks, angle brackets, locating pins, V-blocks, and riser blocks. Build any fixture configuration in minutes.
