10 Ton Adjustable Welding Turning Rolls for Tank Welding
This 10-ton adjustable welding turning roll is specially designed for circumferential welding, assembly and inspection of pressure vessels, storage tanks, boiler cylinders and wind power small tower sections.
Adopt manual screw distance adjustment structure, adapt to different workpiece diameter ranges, equipped with frequency conversion speed regulation drive, stable rotation, low noise, strong load capacity, with complete CE certification, suitable for European, Southeast Asian and domestic heavy machinery processing workshop.
| Item | Parameter |
|---|---|
| Rated Load | 10Ton |
| Roller Adjustment Mode | Manual screw adjustment |
| Applicable Workpiece Diameter | 300mm-2200mm |
| Roller Material | PU rubber roller / Steel roller (optional) |
| Rotation Speed | 0.1-1.0m/min, VFD stepless speed control |
| Drive Mode | Single drive / Double drive optional |
| Power Supply | 380V/400V customized |
| Certification | CE Certificate |
| Application | Tank girth welding, cylinder assembly, non-destructive testing |
-
Adjustable Center DistanceManual lead screw adjusts the roller spacing freely, flexibly matches cylindrical workpieces of different outer diameters, one set of equipment adapts to multi-specification product processing, reduce equipment procurement cost.
-
Anti-scratch PU Roller OptionPolyurethane roller surface will not scratch stainless steel, aluminum alloy workpiece outer wall, suitable for food-grade stainless steel tank, sanitary container welding production. Steel roller for heavy-duty rough machining use.
-
Variable Frequency Speed Control SystemABB/brand inverter motor, stable rotating speed, no shaking during heavy load operation, uniform welding speed to ensure consistent girth weld molding quality.
-
Heavy-duty Frame StructureIntegrated welded base plate, overall stress relief annealing treatment, long-term heavy load operation without deformation, good structural rigidity.
-
Convenient MaintenanceIndependent bearing seat structure, easy to replace bearings and rollers, lubrication grease nozzle design for daily maintenance.
| Comparison Item | Steel Roller | PU Rubber Roller |
|---|---|---|
| Main Advantages | Heavy load, high temperature resistance, wear-resistant | Anti-scratch, anti-slip, shock absorption |
| Workpiece Protection | Easy to scratch stainless steel & polished parts | Keep workpiece surface intact |
| Load Application | For equipment over 20 tons | For equipment below 20 tons |
| Anti-slip Performance | Slip easily at start & stop | Stable rotation without slipping |
| Application Scenarios | Carbon steel tank, heavy rough machining | Stainless steel tank, sanitary tank, aluminum part |
| Cost | Lower purchase cost | Slightly higher cost |
| Maintenance | Regular lubrication only | Replace rubber sleeve directly when worn |
Choose steel rollers for heavy-duty carbon steel workpiece processing with no strict surface protection requirements.
Choose PU rubber rollers for stainless steel, non-ferrous metal and high-precision workpieces that need surface anti-scratch protection.
Packaging: Standard export wooden box / steel frame packing, waterproof and dustproof film, suitable for sea freight container shipment.
Delivery Time: 7-15 working days after deposit confirmation.
Shipping: Support FOB, CIF, DDP and other international trade terms.
After-sales: 12 months warranty and lifelong technical support.
Looking for robust, heavy-duty 10-ton adjustable welding turning rolls to upgrade your workshop? Our heavy-load welding roller sets support countless tank fabrication, boiler and circular part welding factories across the globe. We offer professional technical guidance, on-site installation instructions and extended after-sales guarantee.
Send your enquiry promptly, our sales specialist will offer direct factory cost and customized accessory configuration solutions!
