6 Seats Lithium Battery Golf Club Cart Low Chassis With With Ergonomically Designed Black Seats

Price Negotiable
Price: Negotiable
MOQ: 1
Delivery Time: within 1 months
Brand: LAKER AUTO
Product Description

D1 SERIES ELECTRIC CLUB CART


LAKER AUTO D1 series golf cart adopts sculpted three-dimensional styling. Its layered front fascia boasts well-defined structural contours, matched with premium windshields and an integrated black sun canopy for a cohesive look. Crisp, streamlined lines run along the vehicle side. Ergonomically shaped black seats deliver optimized lumbar and body support to prevent fatigue during long rides, creating a sleek, modern and premium overall aesthetic.


Fitted with a CMOS continuously variable transmission system, it is equipped with automatic electronic braking and anti-rollback protection. The system automatically limits speed when descending slopes, enabling smart, secure handling.


The front axle features double-wishbone independent suspension paired with heavy-duty coil springs and tubular hydraulic shock absorbers. This setup effectively dampens vibrations from uneven ground, significantly smoothing out bumpy rides for superior driving comfort.


Data Sheet


Model L4
Seats 4 Seats
Range 100km
Battery Capacity 7.7kw.h
Size 3120*1330*2075mm
Max. Speed ≤40km/h
Motor 5KW
Braking Distance ≤4m
Min. Turning Radius ≤4.5m
Axle Distance 2115mm
Kerb Weight 570kg
Min. Ground Clearnce 180mm
Climibing Abilty ≤15%
Breaks Hydraulic dual-circuit four-wheel disc brakes with electronic parking.
Suspensions Double Swing Arm Inde pendent Front Suspension.
Trailing arm independent rear suspension.


 More Models


Specification Configuration Sheet D1H2 D102 D1H4 D104 D1H6 D106
Passenger Capacity 2 seats 2 seats 4 seats 4 seats 6 seats 6 seats
L*W*H(mm) 2420*1350*2010 2420*1260*1850 3210*1350*2040 3180*1260*1880 3960*1350*2040 3930*1260*1880
Range (48V150Ah Standard Battery) 80km 80km 70km 70km 70km 70km
Battery Capacity 7.2kw.h 7.2kw.h 7.2kw.h 7.2kw.h 7.2kw.h 7.2kw.h
Max. Speed ≤40km/h ≤25km/h ≤40km/h ≤25km/h ≤32km/h ≤25km/h
Motor 5kw 5kw 5kw 5kw 5kw 5kw
Braking Distance ≤3.5m ≤3.5m ≤4m ≤5m ≤4.5m ≤4.5m
Min. Turing Radius ≤3.5m ≤3.5m ≤5m ≤5m ≤6.5m ≤6.5m
Axle Distance 1670mm 1650mm 2420mm 2400mm 3170mm 3155mm
Kerb Weight 609kg 602kg 704kg 674kg 755kg 736kg
Min.Ground Clearance 180mm 110mm 180mm 110mm 180mm 110mm
Climbing Ability ≤15% ≤15% ≤15% ≤15% ≤15% ≤15%
Brakes                               Hydraulic dual-circuit four-wheel disc brakes with electronic parking
Suspensions                      Swing Arm Independent Front Suspension. Trailing arm independent rear suspension


About LAKER AUTO


Having deeply rooted in overseas markets for years, LAKER AUTO accurately grasps global customer needs, fully understands the strengths and weaknesses of Chinese EV vehicle manufacturers and products, precisely identifies the standards of EV models suitable for overseas markets, and integrates high-quality manufacturer resources, focusing on the customized R&D and global export of a full range of mobile products, covering various scenario-specific models, including:

·  Recreational & Sightseeing: Golf carts (2-8 seater) for courses/estates; Sightseeing buses (8-23 seater) for resorts/parks.

·  Industrial & Utility: Industrial golf carts, utility vehicles (UTVs), and tracked carriers.

·  Emergency & Sanitation: Water sprinklers, fire trucks, sanitation trucks, and emergency toilet vehicles.

·  Support Trailers: Enclosed cargo trailers, mobile food carts, and mobile toilet trailers.



More than a provider of high-quality mobile tools, we take scenarios as the core, creating customized solutions for global customers to meet multi-dimensional needs such as leisure, business and emergency, empowering the upgrade of scenario value.


◇ Full-Dimensional Customization for Global Demand

Adhering to the four core principles of customization, scenarioization, global compliance and local adaptation, LAKER AUTO relies on 100% personalized customization capabilities and assigns one-on-one exclusive consultants to follow up the whole process to ensure the precise implementation of customer needs.

We can tailor high-adaptability and cost-effective exclusive products according to certification standards and voltage specifications of different countries, combined with the needs of diverse scenarios such as scenic spots, commercial streets and industrial parks, as well as customers' functional preferences for size, color, appearance, layout, power system, etc.



◇ Worry-Free Whole Process, Escorting Global Delivery

LAKER AUTO has built a full-chain closed-loop service system of "Consultation-Design-Production-Inspection-Logistics-After-sales", providing one-stop solutions for design, production and export. From demand communication to product delivery, and subsequent after-sales support, professional personnel are assigned to connect the whole process, eliminating the need for customers to worry about intermediate links, allowing global customers to easily obtain mobile products that meet their own needs and efficiently develop local markets.


◇ Empowering Business Growth, Upgrading Scene Experience

LAKER AUTO always believes that high-quality mobile products are not only tools, but also extensions of scenario value.

Our products have three core values:

1.As a mobile business tool, they can realize integrated operation of flexible entrepreneurship, rental and sales, helping customers recover costs and make profits quickly;

2.As leisure scene equipment, they can significantly improve travel comfort and adapt to the upgrade of scenarios such as cultural tourism and resorts;

3.As emergency support equipment, they can meet emergency needs in special scenarios, fully covering customers' diversified application scenarios.
