Transformer Comprehensive Tester Instrument Transformer Testing Ct Pt Analyzer

Price Negotiable

Price: 3000usd

MOQ: 1

Delivery Time: 1 week

Brand: MINGYANG

Product Description

Transformer Comprehensive Testing Instrument

Advanced CT/PT analyzer for comprehensive transformer testing with precision measurement capabilities.

Technical Specifications

AC Current Source

Single phase current output (RMS)	0 - 30A/phase, accuracy: 0.2% ± 5mA
Six phase parallel output (RMS)	0-180A/six parallel outputs with the same phase
Allowable working value of phase current for long time	9.9A
Maximum output power	Per phase 320VA
Maximum output power of six phase parallel current	1800VA
Maximum output allowable working time of six-phase parallel current	5s

General Parameters

DC Current Source

DC current output

0-±10A/phase, accuracy: 0.5% ± 5mA

AC Voltage Source

Single phase voltage output (RMS)	0 - 120V/phase, accuracy: 0.5% ± 5mV
Line voltage output (RMS)	0-240V
Phase voltage/line voltage output power	75VA/100VA
Frequency range	0 - 1000Hz, accuracy: 0.001Hz

DC Voltage Source

Single phase voltage output amplitude	0-±160V, accuracy: 0.5% ± 5mV
Output amplitude of line voltage	0-±320V
Phase voltage/line voltage output power	90VA/180VA

Switching Value Terminal

Switch input terminal	8 pairs
Idle contact	1-20mA, 24V, internal active output of the device
Potential reversal	Passive contact: low resistance short circuit signal Active contact: 0-250V DC
Switch output terminal	4 pairs, empty contacts Interruption capacity: DC: 0-30V/5A, AC: 0-250V/5A

Additional Specifications

Time frame	1ms - 9999s, measuring accuracy: 1ms
Volume and weight of single machine	Volume: 418363208mm³, approximately 17.8kg
Power Supply	AC220V±10%, 50/60Hz, 10A

AC Current Working Time Specifications
