High Voltage Switch Circuit Breaker Analyzer 12 Channels Circuit Breaker Test Set
12 Channels Circuit Breaker Test Set for comprehensive mechanical characteristic parameter testing of high voltage switches in power systems.
The SXGK series 12 Channels Circuit Breaker Test Set is designed for testing and measuring mechanical characteristic parameters of high voltage switches including vacuum, SF6, oil, and other power system circuit breakers. With stable measurement data and strong anti-interference capability, it performs reliable experiments in power stations up to 500KV level, featuring convenient wiring and simple operation for efficient high-voltage switch maintenance testing.
- 12 measurement channels for comprehensive testing
- Advanced graphical analysis capabilities
- Integrated time-delay protection systems
- Complete reclosing test functionality
- High-precision timing and velocity measurements
- Robust anti-interference technology
- User-friendly operation with convenient wiring
| Parameter | Specifications |
|---|---|
| Time Measurement | 12 natural switching (closing) time, opening/closing phase synchronization, bounce time measurement, internal trigger: 0.01ms-10000ms, external trigger: 0.01ms-200000ms |
| Velocity Measurement | Instant separating/closing velocity, average velocity in appointed segments, range: 1mm sensor 0.01-25.00m/s, 0.1mm sensor 0.001-2.50m/s |
| Travel Measurement | Moving contact travel, contact stroke, over travel, overshoot/rebound stroke, linear sensor: 50mm range (0.1mm resolution), optional 100-1000mm sensors |
| Current & Resistance | Maximum current: 30A (0.01A resolution), resistance: 1000Ω (0.01Ω resolution) |
| Power Supply | AC 220V ±10%, 50Hz ±10%, DC output: 20-270V adjustable, 4400W power |
| Operating Environment | Temperature: -20°C to +50°C, Relative humidity: ≤90% |
| Dimensions | 36*26*17cm (mainframe) |
Sansion Power Electric was established in 2005, a technocrat who have rich experience of more than 20 years in R&D, manufacturing and marketing of power electrical testing products, which are widely used in the fields of power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace and etc.
Sansion Power Electric contains R&D department, instruments manufacturing workshop, HV workshop, sample exhibition room, HV testing laboratory, quality control department, general office, sales departments, information office and ete, now we have more than 80 employees including 20 technical engineers. We have obtained the IS09001 quality system certification and all products strictly conform to theinternational lEC and Chinese state standards.
A: Sansion Power Electric Co., Ltd. is an industrial and trade enterprise, with its own factory, self-produced and self-sold. We were founded in 2005 and have twenty years of production experience. Our company has reliable production lines, test rooms and R&D centers.
A: After the goods have been ordered, we can be made to order according to the special requirements of customers by using the latest technology. The delivery time is usually within 10 working days if there are no accidents.
A: In order to ensure quality, we use imported components in large quantities. After three times of quality inspection, the goods can be sent out, and the export is uniformly packed in non-fumigation wooden boxes.
A: What are the after-sales terms?
We offer free consulting service, one year warranty, and adopt various methods such as email communication, video calls, technology door-to-door, aiming to solve any after-sales problems in a timely manner.
A: Products have been successfully exported to the United States, French ,Brazil, Australia, Spain, Portugal , Oman ,Russia, the Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia and other countries and regions.
