High Precision AC Motor Comprehensive Test Bench GB/T755-2019 GB/T14711-2013
Price:
US $1,000-50,000 /
MOQ:
1 Set
Delivery Time:
Negotiable
Brand:
Sansion
Product Description
High-Precision Motor Comprehensive Test Bench for Electric Motor Testing
AC Motor Performance Testing Equipment For Torque-Speed Characteristic Test
General Information
The SXDJ AC Motor Performance Testing Equipment conforms to GB/T755-2019, GB/T14711-2013, GB/25442-2010 and other relevant national standards. This custom-designed test bench meets specific technical requirements and motor type specifications while ensuring compliance with standard usage requirements.
Designed with principles of safety, reliability, economy, practicality, ease of operation and scalability, this advanced system performs complex test functions for both high and low voltage three-phase asynchronous motors and DC motors.
Product Features
- Engineered for reliability, safety, economy, practicality, operability, and maintainability while maintaining technological advancement
- Measurement and control system utilizes industrial control computer + PLC control + digital display measuring instrument
- All test benches, electrical control cabinets, and box surfaces feature spray treatment with clear, durable markings
- All equipment and installation materials consist of new components using international unit (SI) standards
Technical Specifications
| Main Testing Items | Insulation resistance test High and low voltage motor no-load loss and no-load current measurement High and low voltage motor power frequency withstand voltage test High and low voltage motor inter-turn withstand voltage test Three/single phase voltage and average voltage measurement Three/single phase current and average current measurement Vibration measurement DC winding Resistance test Temperature measurement |
| Applicable To | Routine testing on 300KW three phase motor |
Major Components
Front Power Source: 300kW regulator and 300kW transformer as front system power source
Measuring Control: High-precision electrical parameters test unit meeting precision electrical measurement requirements for various models/levels of motors
Main components utilize well-known brands for optimal performance and reliability
System Features
This motor test system delivers comprehensive, high-precision evaluation for motors up to 300kW (110V/240V/415V). It seamlessly performs a full suite of tests including no-load (loss & voltage imbalance), winding resistance, turn-to-turn and power frequency withstand, and insulation resistance, with all results clearly displayed and printable.
Driven by a high-performance MCU and advanced algorithms, it utilizes high-speed A/D conversion and precision signal conditioning to ensure exceptional reliability and accuracy. Operation is intuitive via a fully English interface with guided menus, supporting both PLC automation and manual control for effortless step-by-step testing.
Company Profile
About Sansion
Sansion Power Electric was established in 2005, with over 20 years of experience in R&D, manufacturing and marketing of power electrical testing products. Our solutions are widely used in power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace and other fields.
Our facility includes R&D department, instruments manufacturing workshop, HV workshop, sample exhibition room, HV testing laboratory, quality control department, and employs over 80 staff including 20 technical engineers. We maintain ISO9001 quality system certification and all products strictly conform to international IEC and Chinese state standards.
Certifications
Packing & Delivery
Customer Visit
Frequently Asked Questions
Q1: Is your company a sales company or a manufacturer?
A: Sansion Power Electric Co., Ltd. is an industrial and trade enterprise, with its own factory, self-produced and self-sold. We were founded in 2005 and have twenty years of production experience. Our company has reliable production lines, test rooms and R&D centers.
Q2: Whether the goods are in stock, whether they can be customized, and how long the delivery time is?
A: After the goods have been ordered, we can be made to order according to the special requirements of customers by using the latest technology. The delivery time is usually within 10 working days if there are no accidents.
Q3: Is the quality guaranteed?
A: In order to ensure quality, we use imported components in large quantities. After three times of quality inspection, the goods can be sent out, and the export is uniformly packed in non-fumigation wooden boxes.
Q4: What are the after-sales terms?
A: We offer free consulting service, one year warranty, and adopt various methods such as email communication, video calls, technology door-to-door, aiming to solve any after-sales problems in a timely manner.
Q5: What are the cooperative countries or regions?
A: Products have been successfully exported to the United States, French, Brazil, Australia, Spain, Portugal, Oman, Russia, the Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia and other countries and regions.
