High Voltage Electric Motor Test Stand For Inter Turn Withstand Voltage Testing
Price:
US $1,000-50,000 /
MOQ:
1 Set
Delivery Time:
Negotiable
Brand:
Sansion
Product Description
High Voltage Testing Equipment Electric Motor Test Stand
Professional testing system for inter-turn withstand voltage testing of electric motors with comprehensive analysis capabilities.
Product Overview
The SXDJ Electric Motor Test Stand is designed for ex-works and post-maintenance testing of AC motors, DC motors, and variable frequency motors with capacities ranging from 0-10000kW and voltage levels of 0-10kV.
This integrated system combines industrial PC, power source system, control system, sensors, signal conditioning modules, data acquisition hardware and software, numerical computing software, graphical display and operation software, test report generation, and waveform and measurement results storage and printing capabilities.
Key Benefits
- Compliance: Supports testing per IEC 60034, IEEE 112, GB 755 and other international standards
- Precision: High-speed data acquisition and advanced signal conditioning ensure reliable results
- Flexibility: Modular design allows customization for different motor types (AC/DC, HV/LV, servo, EV traction motors)
- User-Friendly: Fully English GUI with guided workflow reduces operator training time
Testing Capabilities
| Main Testing Items | √ Electric Strength √ Measuring Condition √ Insulation Resistance √ Cold Resistance √ Low Starting Current √ Locked-rotor Current √ No-Load Power √ No-Load Current √ Leakage Current √ Turn-To-Turn Insulation |
System Features
- Complete testing capabilities for 300kW/110V/240V/415V motors including no-load tests, no-load loss, three-phase voltage unbalance test, DC winding resistance test, turn-to-turn voltage withstand test, insulation resistance and power frequency voltage withstand test
- Comprehensive measurement parameter display and menu-driven parameter setting
- All test data can be displayed and printed for documentation
- High-quality SCM processor with unique scientific algorithms for data computing and processing
- High-speed fast A/D converter for analog-digital conversion with advanced signal processing technology
- PLC and manual control options with multilevel menu guidance for step-by-step testing
- Fully English interface for easy operation
Product Images
Company Profile
Sansion Power Electric was established in 2005, with over 20 years of experience in R&D, manufacturing, and marketing of power electrical testing products. Our solutions are widely used in power electric, railroad, energy conservation and environment protection, water conservancy, petrochemical industry, aerospace, and other critical sectors.
Our facility includes R&D department, instruments manufacturing workshop, HV workshop, sample exhibition room, HV testing laboratory, quality control department, and comprehensive administrative offices. With over 80 employees including 20 technical engineers, we maintain ISO9001 quality system certification and ensure all products strictly conform to international IEC and Chinese state standards.
Frequently Asked Questions
Is your company a sales company or a manufacturer?
Sansion Power Electric Co., Ltd. is an industrial and trade enterprise with its own factory, self-produced and self-sold. Founded in 2005, we have twenty years of production experience with reliable production lines, test rooms, and R&D centers.
Are goods in stock, can they be customized, and what is the delivery time?
We manufacture to order according to customer specifications using the latest technology. Delivery time is typically within 10 working days under normal circumstances.
Is the quality guaranteed?
We use imported components extensively and conduct three quality inspections before shipment. All exports are packed in non-fumigation wooden boxes for secure transportation.
What are the after-sales terms?
We offer free consulting service, one-year warranty, and multiple support methods including email communication, video calls, and on-site technical support to resolve any after-sales issues promptly.
What are the cooperative countries or regions?
Our products have been successfully exported to the United States, France, Brazil, Australia, Spain, Portugal, Oman, Russia, the Netherlands, Indonesia, Bangladesh, Saudi Arabia, Chile, Colombia, Panama, Malaysia, and other countries and regions worldwide.
