2400kv AC Lightning Impulse Withstand Voltage Test System Fully Automated Operation
Price:
1000
MOQ:
1 Set
Delivery Time:
Negotiable
Brand:
Sansion
Product Description
2400kV AC Lightning Impulse Voltage Withstand Test System
The SXCF Series AC Lightning Impulse Voltage Withstand Test System is designed for lightning impulse voltage full-wave, chopped-wave (optional), and switching surge (optional) testing of electrical equipment and other test products to verify insulation performance.
Key Features
- Stable Waveform: Utilizes Mitsubishi FX Series programmable logic controller with simplified architecture for high reliability
- Fully Automated Operation: Intuitive interface designed for high-voltage testing workflows with dedicated program operation
- Extended Service Life: Advanced technology and quality materials ensure operational reliability exceeding 20 years
- Compact Main Structure: Modern design with low inherent inductance and simplified waveform adjustment
- Integrated Measurement and Control: Fiber-optic control transmission system eliminates electromagnetic interference
Chopping Gap: Performs cut-wave tests for comprehensive insulation analysis
Shunt Resistor: Ensures accurate current waveform recording during tests
Technical Specifications
| Parameter | Specification |
|---|---|
| Impulse Voltage Grade | 100kV-7200kV |
| Standard Lightning Wave | 1.2±30%/50±20%µS |
| Peak Oscillation | 5% |
| Standard Switching Wave | 250±20%/2500±60%µS |
| Virtual Front Time of Oscillating Lightning Wave | 15µS |
| Virtual Front Time of Oscillating Switching Wave | 15µS-1µS |
| Minimum Output Voltage | 10%Un |
| Charging Voltage Instability | 1% |
| Synchronizing Range | 20% |
| Synchronous Discharge Error Rate | 2% |
| Ignition Range | 10%-100% |
| Working Time | 70%UN Discontinuous work (charge-discharge 300s/time) 70%nn Continuous work (charge-discharge 120s/time) |
| Generator Efficiency | Lightning wave (no load) - 90% |
| Time to Chopping | 2-5µS |
