Lightning Impulse Voltage Generator Impulse Withstand Voltage Tester for Insulator
Price:
1000
MOQ:
1 Set
Delivery Time:
Negotiable
Brand:
Sansion
Product Description
Lightning Impulse Withstand Voltage Tester for Insulator Testing
The SXCF Series Lightning Impulse Withstand Voltage Tester is designed for impulse voltage testing using lightning impulse voltage full wave, lightning impulse voltage chopped wave, and operating impulse voltage wave for electrical instruments and equipment.
Key Features
- Complete equipment with wide voltage level coverage
- Small electric inductance in return circuit with band-stop filtering for standard impulse waves under large capacity loads
- High voltage utilization coefficient
- Convenient wave adjustment with simple operation and excellent synchronization
- Automatic control technology for constant-current charging with high automation
- Digital measurement and analysis system for impulse test data
Chopping Gap
Performs cut-wave tests with precision and reliability
Shunt Resistor
Ensures accurate current waveform recording during tests
Technical Specifications
| Parameter | Specification |
|---|---|
| Impulse Voltage Grade | 100kV-7200kV |
| Standard Lightning Wave | 1.2±30%/50±20%µS |
| Peak Oscillation | 5% |
| Standard Switching Wave | 250±20%/2500±60%µS |
| Virtual Front Time of Oscillating Lightning Wave | 15µS |
| Virtual Front Time of Oscillating Switching Wave | 15µS-1µS |
| Minimum Output Voltage | 10%Un |
| Charging Voltage Instability | 1% |
| Synchronizing Range | 20% |
| Synchronous Discharge Error Rate | 2% |
| Ignition Range | 10%-100% |
| Working Time | 70%UN Discontinuous work (charge-discharge 300s/time) 70%nn Continuous work (charge-discharge 120s/time) |
| Generator Efficiency | Lightning wave (no load) - 90% |
| Time to Chopping | 2-5µS |
