Painted Steel Industrial Sectional Overhead Door For Warehouse Exterior

Price Negotiable

Price: Negotiable

MOQ: IUNIT

Delivery Time: 10~15DAYS

Brand: YOHO

Product Description

High Quality Warehouse Exterior Adapted Different Industrial Sectional Doors

Our premium industrial sectional doors are engineered for warehouse exterior applications, offering exceptional durability and adaptability across various industrial environments. These high-performance doors provide reliable operation and superior protection for your facility.

Specifically designed for warehouse exterior installations

Adaptable to different industrial settings and requirements

Robust construction for long-lasting performance

Superior weather resistance and insulation properties

Customizable sizing to fit various opening dimensions

Enhanced security features for industrial applications

Item	Description
Material	SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate
Thickness of Panel Mateiral	0.326 / 0.45mm / 0.55mm / 0.6mm
Thickness of Guiding Rail	Gualvanized Steel,thickness: 2mm
Thickness of Panel	40mm / 50mm
Width of Panel	430mm / 550mm
Density of Sandwiches	48kg/m3
Surface Treatment	Power coating,thickness of coating:30um
Heat Preservation	4.5W/m.h
Wind Resistance	Beaufort scale 11, 28m/s
Noise Level:	≤60db
Sound Insulation Level	24 Db
Fire Retardation:	Class A
Speed	0.2-0.4m / s
Max Dimension	12m * 8m
Sealing Performance	EPDM rubber all round sealing : two side, top, bottom,between door panels
Steel cord	Flexible ,3.8mm
Power Supply	380V 50Hz / 220V 50Hz
Service Life	10 years
Emergency Operation	Manual Hoist Chain to open the door in case of power off
Balance System	a. Balance the weight of door through the torsion spring b. Easily manual operation: 140N to open c. Spring brake device:Anti-broken device d. Service Life:100 thousand open & close e. Prolong the service life of the motor
Safety	Airbag protection, door anti-fall device, wire rope anti-break protection device.
Optional Item	Window,pedestrian door
