High Performance SUS304 SUS316 Industrial High Speed Door For General Manufacturing
Ensuring Durability And High Efficiency Industrial High Speed Door For General Manufacturing
The Industrial High Speed Door for General Manufacturing with stainless steel construction is designed for factories that require durability, efficiency, and stable operation across various production processes.
In general manufacturing environments, internal logistics, personnel movement, and material transfer occur frequently. This stainless steel high speed door combines fast operation, corrosion resistance, and robust structure, ensuring smooth traffic flow while withstanding harsh industrial conditions.
Product Specifications
| Material | PVC Curtain / Stainless steel |
|---|---|
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable) |
| Curtain Material | 0.8/1.2/1.5/2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for optimal sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control |
Product Features
-
Stainless Steel Structure: SUS304 (standard), SUS316 optional
-
Large Size Capability: Door width up to 6000 mm, height up to 6000 mm
-
Curtain Material: PVC curtain 0.8/1.2/1.5/2.0 mm, optional vision panels
-
Servo Control System: DSP-based controller with encoder feedback and LED fault display
-
Sealing System: Side brush seals + EPDM bottom soft safety edge
-
Wind Resistance: Standard Grade 6, reinforced up to Grade 8
-
Safety Devices: Infrared photoelectric sensors, bottom safety edge, emergency stop
-
Activation Options: Push button, radar sensor, ground loop, pull rope, remote control
-
Emergency Manual Operation: Available during power failure
-
Protection Class: IP54 control cabinet
Stainless Steel Structure & High-Frequency Operation
General manufacturing environments demand reliable and robust equipment.
-
Material: SUS304 stainless steel (SUS316 optional)
-
Strong Structure: Suitable for frequent forklift and equipment traffic
-
Long Service Life: Resistant to corrosion and mechanical wear
This design ensures stable performance and reduced downtime.
Applications
-
General manufacturing workshops
-
Production line access points
-
Internal factory passages
-
Warehouse-to-workshop connections
-
Equipment operation corridors
FAQ
Q1: Why choose stainless steel high speed doors for general manufacturing?
Stainless steel offers durability, corrosion resistance, and long service life in diverse industrial environments.
Q2: Is the door suitable for high-frequency operation?
Yes. The servo motor system supports thousands of cycles per day, ideal for busy manufacturing facilities.
Q3: Can the door be customized for different factory layouts?
Yes. Door size, stainless steel grade, curtain material, and control systems can be customized.
Q4: Does the door require special maintenance?
No. The smooth stainless steel surface reduces maintenance needs and supports easy cleaning.
