0.75KW-1.5KW Industrial High Speed Door For Supermarket Back Room / Storage Area
Industrial High Speed Door With Efficient Workflow For Supermarket Back Room / Storage Area
The Industrial High Speed Door for Supermarket Back Rooms and Storage Areas is designed to improve workflow efficiency, maintain cleanliness, and ensure energy efficiency in storage and loading areas.
Supermarket back rooms and storage areas require frequent access for goods handling, forklifts, and staff. This door features a durable PVC curtain, galvanized steel frame, and fast opening/closing, minimizing dust, temperature loss, and contamination while ensuring smooth internal logistics.
Product Specifications
| Material | PVC curtain / Galvanized steel / Stainless steel |
|---|---|
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.8-2.0 m/s (adjustable); Closing Speed: 0.5-0.8 m/s (adjustable) |
| Curtain Material | 0.8 - 2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for optimal sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control |
PVC Curtain & Galvanized Steel Frame
The PVC curtain and galvanized steel frame combination ensures durable, safe, and cost-effective operation in supermarket storage areas.
- PVC Curtain: Flexible, lightweight, and durable, reducing maintenance costs
- Galvanized Steel Frame: Resistant to impact, corrosion, and heavy use
- High-Speed Operation: Fast access reduces workflow bottlenecks
- Safety Features: Infrared sensors and soft bottom edge protect personnel and goods
This design ensures smooth material flow, safe operation, and long-lasting performance.
Product Advantages
Efficient Workflow
- Fast opening and closing reduce waiting time for staff and forklifts
- Supports frequent material movement and high turnover of goods
Energy & Environmental Control
- Tight sealing reduces air exchange between storage areas and external environment
- Helps maintain stable temperature for food storage and energy efficiency
Durable & Cost-Effective
- PVC curtain resists wear and tear from frequent use
- Galvanized steel frame ensures long service life at a lower cost
FAQ
Q1: Why use high speed doors in supermarket back rooms?
They improve workflow efficiency, reduce waiting times, and maintain a cleaner and more energy-efficient storage environment.
Q2: Is the door suitable for frequent forklift traffic?
Yes. The PVC curtain and galvanized steel frame are designed for high-frequency use in logistics-heavy areas.
Q3: Can the door help control temperature and dust?
Yes. The tight sealing system reduces airflow, dust, and contamination between zones.
