Heavy Duty Insulated High Speed Door Aluminum Alloy Rapid Garage Door For Logistics Center Aisle
Aluminum Alloy Rapid Spiral Door High Speed Heavy Duty Insulated For Logistics Center Aisle
Product Overview
The Spiral High Speed Door is widely used in logistics center passages, where forklifts, pallet trucks, and automated vehicles move continuously between different functional zones.
In high-throughput logistics environments, a Rigid Spiral High Speed Door ensures fast opening, stable operation, and long service life under intensive daily use.
Also known as a Turbo High Speed Door or Spiral Lift High Speed Door, this solution is designed for modern logistics hubs and distribution centers.
Product Specifications
| Parameter | Description |
|---|---|
| Maximum Available Size | Door width: 1000–7000 mm Door height: 1500–5000 mm |
| Lifting Mechanism | The aluminum alloy turbine guide rail ensures high-speed operation of the door curtain during opening and closing. The rotational friction between the door curtain and the rail effectively controls noise. Based on the on-site installation structure, it can be divided into: turbine suction type, elliptical suction type, vertical lifting type, 90-degree standard corner lifting type, or other rail configurations. The standard configuration is the turbine suction type; other lifting methods require prior arrangement with our sales personnel. |
| Operating speed | Opening speed: 0.6-1.5 M/S (adjustable) Closing speed: 0.6 M/S (adjustable) |
| Door panel materials | The aluminum alloy door panel has a width of 120mm and a standard thickness of 24mm, with two reinforcing ribs inside. The door panel is filled with polyurethane foam, the aluminum alloy door sheet thickness is 1.2mm, the door hinge thickness is 45mm, and the spiral track thickness is 10mm. Various colors are available. |
| Sealing performance | Multiple seals, including guide rail seals, door panel middle seals, and door body bottom seals, ensure airtightness and isolation between the inside and outside of the door. |
| Wind resistance | Maximum wind speed of 8 on the Beaufort scale, which may intensify to 10 on the Beaufort scale. |
| Manual functions | In the event of a power outage, the motor brake can be released at any time, and the door can be lifted using the balancing system. This effectively solves the problem of the door being unable to open due to power failure or malfunction. |
| Switching method | Standard one-button control box with emergency stop switch. Optional features include: radar sensing, magnetic loop sensing, pull-cord switch, and remote control activation. |
| Reserved port | The electrical control system includes provisions for: infrared safety switches, magnetic induction switches, radar induction switches, pull-cord switches, remote control switches, and double-door interlocking, ensuring strong compatibility. |
Details Parts of Door
Advantages of Spiral High Speed Doors in Logistics Passages
- Supports continuous forklift and AGV traffic
- Reduces congestion in logistics corridors
- Operates as a Low Noise High Speed Door
- Handles thousands of cycles per day
- Requires minimal maintenance
- Enhances safety and operational efficiency
Detailed Feature Focus: High-Cycle Servo Control System
In logistics centers, doors may open and close thousands of times daily.
The Rigid Spiral High Speed Door uses a servo-driven system with closed-loop control for torque, speed, and position, ensuring accurate operation even under constant use.
This makes it a reliable High Cycle Industrial High Speed Door for logistics environments.
Comparison with Other High Speed Door Types
Spiral High Speed Door vs PVC Roll-Up Door
PVC doors wear quickly under frequent forklift impact and lack rigidity.
Spiral High Speed Door vs Sectional Door
Sectional doors cannot meet the speed and cycle requirements of logistics passages.
Spiral High Speed Door vs Stacking Door
Stacking doors are suitable for very large openings but operate at lower speeds.
FAQs – Spiral High Speed Door for Logistics Center Passages
Q1: Is this door suitable for high-frequency forklift traffic?
Yes. It is designed as a High Cycle Industrial High Speed Door.
Q2: Can it integrate with logistics automation systems?
Yes. It supports radar, loop sensors, and interlock signals.
Q3: Does it improve safety in busy corridors?
Yes. Vision panels and fast response reduce collision risks.
Q4: Do you support OEM and export projects?
Yes. We provide OEM Spiral High Speed Door solutions worldwide.
