Industrial Spiral High Speed Door Waterproof Custom For Industrial Park Passageways
High-Speed Plastic Spiral Door Modern Waterproof Feature Electric Side Opening For Industrial Park Passageways
Product Overview
Industrial parks contain multiple factories, warehouses, and logistics hubs where smooth traffic flow and controlled access are essential. Frequent vehicle and forklift movements require doors that operate rapidly, reliably, and safely, while providing separation between production and logistics areas.
The Spiral High Speed Door is ideal for industrial park passageways, offering rigid aluminum panels, non-contact spiral track technology, and high-speed servo motor operation. It ensures efficient movement of personnel and materials, enhances safety, and minimizes environmental disturbances.
Product Specifications
| Parameter | Description |
|---|---|
| Maximum Available Size | Door width: 1000–7000 mm Door height: 1500–5000 mm |
| Lifting Mechanism | The aluminum alloy turbine guide rail ensures high-speed operation of the door curtain during opening and closing. The rotational friction between the door curtain and the rail effectively controls noise. Based on the on-site installation structure, it can be divided into: turbine suction type, elliptical suction type, vertical lifting type, 90-degree standard corner lifting type, or other rail configurations. The standard configuration is the turbine suction type; other lifting methods require prior arrangement with our sales personnel. |
| Operating speed | Opening speed: 0.6-1.5 M/S (adjustable) Closing speed: 0.6 M/S (adjustable) |
| Door panel materials | The aluminum alloy door panel has a width of 120mm and a standard thickness of 24mm, with two reinforcing ribs inside. The door panel is filled with polyurethane foam, the aluminum alloy door sheet thickness is 1.2mm, the door hinge thickness is 45mm, and the spiral track thickness is 10mm. Various colors are available. |
| Sealing performance | Multiple seals, including guide rail seals, door panel middle seals, and door body bottom seals, ensure airtightness and isolation between the inside and outside of the door. |
| Wind resistance | Maximum wind speed of 8 on the Beaufort scale, which may intensify to 10 on the Beaufort scale. |
| Manual functions | In the event of a power outage, the motor brake can be released at any time, and the door can be lifted using the balancing system. This effectively solves the problem of the door being unable to open due to power failure or malfunction. |
| Switching method | Standard one-button control box with emergency stop switch. Optional features include: radar sensing, magnetic loop sensing, pull-cord switch, and remote control activation. |
| Reserved port | The electrical control system includes provisions for: infrared safety switches, magnetic induction switches, radar induction switches, pull-cord switches, remote control switches, and double-door interlocking, ensuring strong compatibility. |
Key Features of Spiral High Speed Doors
Rigid Aluminum Door Panels
High-strength aluminum panels resist deformation, impacts, and frequent use in industrial park settings.
Non-Contact Spiral Track System
The spiral track allows panels to lift without friction, reducing wear, noise, and operational disturbances.
Servo Motor Drive System
Provides precise and reliable control, even during continuous high-frequency operation.
Low Noise & Smooth Operation
Quiet operation ensures minimal disruption to nearby production and office areas.
Advantages of Spiral High Speed Doors in Industrial Parks
-
Reduces time lost waiting at passageways
-
Improves traffic flow and operational efficiency
-
Maintains separation between warehouses, factories, and logistics zones
-
Long service life with minimal maintenance
-
Supports large or high-traffic openings
This makes it a preferred industrial high speed door for industrial park passageways.
Detailed Feature Focus: Spiral Track Structure
The spiral lift mechanism allows panels to move independently along curved tracks, providing:
-
Reduced mechanical wear
-
Cleaner operation with minimal dust or debris
-
Stable performance under high-frequency cycles
Compared with PVC roll-up or sectional doors, spiral doors provide superior durability, safety, and efficiency.
Why Choose a Spiral High Speed Door for Industrial Parks?
Industrial park passageways face high traffic, mixed vehicle types, and continuous internal logistics, making fast and reliable door operation crucial:
-
Minimizes waiting time for forklifts, AGVs, and transport vehicles
-
Rigid construction resists frequent impacts and heavy use
-
Smooth, low-noise operation protects personnel and equipment
-
Supports high-cycle industrial traffic
The Spiral High Speed Door is perfect for combining speed, durability, and reliability in industrial park environments.
Customization & Optional Configurations
-
Custom dimensions and height
-
Panel color and finish options
-
Vision windows for visibility
-
Activation: radar sensor, pull cord, push button
-
Safety systems and interlocking integration
OEM and export configurations are available.
FAQs
Is a Spiral High Speed Door suitable for industrial park passageways?
Yes, it is ideal for warehouses, production facilities, and logistics corridors.
Can it handle frequent industrial traffic?
Yes, it is designed for high-cycle industrial operation.
Does it support environmental separation and safety?
Yes, tight sealing and rapid operation help maintain safety and separation.
Do you provide OEM and export options?
Yes, we are a professional Spiral High Speed Door manufacturer and supplier.
|
|
|
