Space-Saving Vertical Opening Commercial Sectional Door Heavy-Duty Overhead Sectional Door For Raw Material Storage Areas
Industrial Sectional Overhead Door for Raw Material Storage Areas
An Industrial Sectional Overhead Door, also known as an Industrial Lift-up Door or Warehouse Lift-up Door, is widely used in raw material storage areas within manufacturing plants and industrial facilities. These areas store bulk materials, components, and semi-finished goods, requiring a heavy duty industrial door that provides reliable access, environmental protection, and long-term durability.
Requirements of Raw Material Storage Areas
Raw material storage areas often face frequent forklift traffic, dust exposure, wind pressure, and large door openings. Doors installed in these zones must offer strong structure, good sealing, and stable operation.
The sectional overhead door opens vertically along tracks, making it suitable for both indoor and external-facing raw material warehouses.
Why Sectional Overhead Doors Are Ideal for Raw Material Storage
Strong & Durable for Heavy Materials Handling
Designed as a heavy duty industrial door, the sectional door withstands impacts from pallets, forklifts, and bulk material movement.
Effective Separation Between Storage & Production
The industrial sectional door helps isolate raw material storage from production lines, reducing dust migration and improving process control.
Space-Saving Vertical Opening
The industrial lift-up door with tracks maximizes usable floor space in storage aisles and loading zones.
Structural Design & Operating Principle
Sectional Panel Construction
Available in steel sectional doors or aluminum sectional doors, offering strength and corrosion resistance for industrial storage environments.
Reinforced Tracks & Spring System
Ensures smooth, balanced operation even with large door sizes commonly used in raw material warehouses.
Manual or Automatic Operation
Supports both manual sectional doors and automatic industrial doors depending on usage frequency.
Product Specifications
| Item |
Description |
|---|---|
|
Material |
SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
|
Thickness of Panel Mateiral |
0.326 / 0.45mm / 0.55mm / 0.6mm |
|
Thickness of Guiding Rail |
Gualvanized Steel,thickness: 2mm |
|
Thickness of Panel |
40mm / 50mm |
|
Width of Panel |
430mm / 550mm |
|
Density of Sandwiches |
48kg/m3 |
|
Surface Treatment |
Power coating,thickness of coating:30um |
|
Heat Preservation |
4.5W/m.h |
|
Wind Resistance |
Beaufort scale 11, 28m/s |
|
Noise Level: |
≤60db |
|
Sound Insulation Level |
24 Db |
|
Fire Retardation: |
Class A |
|
Speed |
0.2-0.4m / s |
|
Max Dimension |
12m * 8m |
|
Sealing Performance |
EPDM rubber all round sealing : two side, top, bottom,between door panels |
|
Steel cord |
Flexible ,3.8mm |
|
Power Supply |
380V 50Hz / 220V 50Hz |
|
Service Life |
10 years |
|
Emergency Operation |
Manual Hoist Chain to open the door in case of power off |
|
Balance System |
a. Balance the weight of door through the torsion spring |
|
Safety |
Airbag protection, door anti-fall device, wire rope anti-break protection device. |
|
Optional Item |
Window,pedestrian door |
Installation method
Typical Applications in Raw Material Storage Areas
- Bulk Material Storage Zones
- Component & Parts Warehouses
- Palletized Raw Material Areas
- Forklift Access Entrances
- Internal Logistics Corridors
These use cases make the industrial sectional overhead door a core solution for raw material storage.
Customization Options
Door Size & Opening Configuration
Custom sizes available for large openings and high-clearance storage areas.
Vision Panels & Personnel Doors
Improves visibility and safe staff access without opening the full door.
Surface Finish & Corrosion Protection
Powder-coated or galvanized finishes available for long-term durability.
Frequently Asked Questions (FAQ)
Are sectional overhead doors suitable for dusty raw material areas?
Yes, they offer excellent sealing to reduce dust intrusion.
Can insulated doors be used in raw material warehouses?
Yes, insulated sectional doors help protect temperature- or humidity-sensitive materials.
Can the door handle heavy forklift traffic?
Yes, it is designed as a heavy duty industrial door.
Can door size and configuration be customized?
Yes, full customization is available for industrial projects.
Get a Quote for Industrial Sectional Overhead Doors
We provide technical consultation, OEM services, and bulk order solutions for industrial sectional overhead doors used in raw material storage areas.
|
|
|
