Noise Reducing Sectional Overhead Door Vertical Lift Garage Door For Logistics Areas
Industrial Sectional Overhead Door for Back-of-House Retail Logistics Areas
Back-of-house retail logistics areas are critical support zones where goods are received, stored, sorted, and transferred to sales floors. These spaces require door systems that operate efficiently in tight layouts while supporting frequent staff and equipment movement. An Industrial Sectional Overhead Door offers a compact lift-up solution that improves workflow control and operational efficiency in retail back-of-house environments.
Operational Characteristics of Retail Back-of-House Areas
Frequent Stock Replenishment Cycles
Goods are moved daily from storage to retail shelves, requiring doors that can handle repetitive operation.
Limited Space & Internal Traffic Flow
Back-of-house areas often have narrow passages and shared logistics routes..
Key Features for Back-of-House Retail Applications
Heavy-Duty Industrial Door Panels
Steel or aluminum panels withstand carts, pallet jacks, and daily handling.
Stable Track & Balancing System
Ensures controlled lifting even with frequent open-close cycles.
Effective Sealing Performance
Limits dust and airflow between logistics and retail environments.
Product Specifications
| Item | Description |
| Material | SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
| Thickness of Panel Mateiral | 0.326 / 0.45mm / 0.55mm / 0.6mm |
| Thickness of Guiding Rail | Gualvanized Steel,thickness: 2mm |
| Thickness of Panel | 40mm / 50mm |
| Width of Panel | 430mm / 550mm |
| Density of Sandwiches | 48kg/m3 |
| Surface Treatment | Power coating,thickness of coating:30um |
| Heat Preservation | 4.5W/m.h |
| Wind Resistance | Beaufort scale 11, 28m/s |
| Noise Level: | ≤60db |
| Sound Insulation Level | 24 Db |
| Fire Retardation: | Class A |
| Speed | 0.2-0.4m / s |
| Max Dimension | 12m * 8m |
| Sealing Performance | EPDM rubber all round sealing : two side, top, bottom,between door panels |
| Steel cord | Flexible ,3.8mm |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years |
| Emergency Operation | Manual Hoist Chain to open the door in case of power off |
| Balance System | a. Balance the weight of door through the torsion spring b. Easily manual operation: 140N to open c. Spring brake device:Anti-broken device d. Service Life:100 thousand open & close e. Prolong the service life of the motor |
| Safety | Airbag protection, door anti-fall device, wire rope anti-break protection device. |
| Optional Item | Window,pedestrian door |
Door Panel & Insulation Options
Single-Skin Panels for Standard Retail Storage
Suitable for general backroom logistics areas.
Insulated Sectional Doors for Climate-Sensitive Goods
Helps maintain stable conditions for packaged or temperature-sensitive products.
Improved Indoor Comfort
Supports better working conditions for retail staff.
Safety & Traffic Protection
Mechanical Safety Devices
Includes spring break and cable break protection.
Enhanced Visibility Options
Vision panels help prevent collisions in shared staff areas.
Controlled Door Movement
Reduces risk during busy stocking hours.
Operation & Control Options
Manual Operation for Low-Use Openings
Ideal for secondary storage rooms.
Automatic Operation for Main Logistics Passages
Improves efficiency during peak replenishment periods.
Basic Access Control Integration
Supports authorized staff-only access.
Typical Back-of-House Retail Applications
Receiving & Stockroom Areas
Facilitates delivery handling and goods intake.
Internal Storage & Preparation Rooms
Supports organized inventory movement.
Service Corridors & Staff-Only Passages
Separates logistics traffic from customer areas.
Waste Handling & Return Zones
Provides controlled access for support operations.
Installation & Maintenance
Flexible Installation for Retail Buildings
Compatible with shopping malls, standalone stores, and mixed-use facilities.
Low Maintenance for Daily Retail Operations
Designed for reliable long-term use.
Installation method
FAQ – Back-of-House Retail Logistics Areas
Is a sectional overhead door suitable for small backroom spaces?
Yes, the vertical lift design is ideal for space-limited areas.
Will door noise affect retail operations?
No, smooth operation helps keep noise levels low.
Is automatic operation recommended?
Automatic doors are ideal for main logistics passages with frequent use.
|
|
|
