Weather Sealed Sectional Door Space-Saving Vertical Lift Design For Truck Terminals & Yards
Industrial Sectional Overhead Door for Truck Terminals & Yards
Truck terminals and yards handle a constant flow of freight vehicles, including trucks, trailers, and delivery vans. Doors in these facilities must withstand frequent opening and closing, support large vehicles, and ensure reliable long-term performance. An Industrial Sectional Overhead Door provides a robust lift-up solution that maximizes workflow efficiency, enhances safety, and maintains durability under high-traffic conditions.
Operational Requirements in Truck Terminals & Yards
High-Frequency Vehicle Access
Doors must support continuous truck movements during peak operational hours.
Large Door Openings for Freight Vehicles
Wide and tall doors accommodate trucks, trailers, and loading equipment.
Space-Saving Vertical Lift Design
Keeps loading and maneuvering areas clear for vehicle operations.
Key Features for Truck Terminal Applications
Heavy-Duty Industrial Panels
Steel or aluminum panels resist impacts from trucks and cargo handling equipment.
Reinforced Track & Balanced Spring System
Ensures smooth operation under frequent cycles and heavy loads.
Effective Sealing & Environmental Protection
Protects interiors from dust, drafts, and external weather conditions.
Product Specifications
| Item | Description |
|---|---|
| Material | SUS 304 Stainless Steel,Aluminium Alloy,Color Coating Plate |
| Thickness of Panel Mateiral | 0.326 / 0.45mm / 0.55mm / 0.6mm |
| Thickness of Guiding Rail | Gualvanized Steel,thickness: 2mm |
| Thickness of Panel | 40mm / 50mm |
| Width of Panel | 430mm / 550mm |
| Density of Sandwiches | 48kg/m3 |
| Surface Treatment | Power coating,thickness of coating:30um |
| Heat Preservation | 4.5W/m.h |
| Wind Resistance | Beaufort scale 11, 28m/s |
| Noise Level: | ≤60db |
| Sound Insulation Level | 24 Db |
| Fire Retardation: | Class A |
| Speed | 0.2-0.4m / s |
| Max Dimension | 12m * 8m |
| Sealing Performance | EPDM rubber all round sealing : two side, top, bottom,between door panels |
| Steel cord | Flexible ,3.8mm |
| Power Supply | 380V 50Hz / 220V 50Hz |
| Service Life | 10 years |
| Emergency Operation | Manual Hoist Chain to open the door in case of power off |
| Balance System | a. Balance the weight of door through the torsion spring b. Easily manual operation: 140N to open c. Spring brake device:Anti-broken device d. Service Life:100 thousand open & close e. Prolong the service life of the motor |
| Safety | Airbag protection, door anti-fall device, wire rope anti-break protection device. |
| Optional Item | Window,pedestrian door |
Installation method
Insulation & Environmental Control Options
Single-Skin Panels for Standard Vehicle Areas
Suitable for non-climate-controlled zones and general cargo handling.
Insulated Sectional Doors for Sensitive Goods
Maintains stable conditions for temperature-sensitive freight or equipment.
Noise Reduction & Staff Comfort
Smooth operation reduces noise in nearby offices or dispatch areas.
Operation & Control Options
Manual Operation for Auxiliary Access Points
Cost-effective solution for low-traffic areas.
Automatic Operation for Main Loading Bays
Electric operation improves workflow efficiency and reduces delays.
Integration with Access Control Systems
Optional access control ensures only authorized vehicles and personnel operate the doors.
Typical Applications in Truck Terminals & Yards
Inbound Freight Reception
Facilitates unloading of cargo from trucks and trailers.
Outbound Shipping Zones
Optimizes workflow for loading freight onto delivery vehicles.
Vehicle & Equipment Storage Areas
Provides secure access for forklifts, pallet jacks, and maintenance equipment.
Loading & Unloading Platforms
Supports safe and efficient cargo transfer during peak operations.
Customization Options
Door Size & Track Configuration
Adaptable to large trucks, trailers, and dock dimensions.
Windows, Pass Doors & Accessories
Enhances visibility and safe personnel movement.
Color & Surface Finish Options
Supports facility branding, zoning, and durability.
FAQ – Truck Terminals & Yards
Can sectional overhead doors handle frequent truck traffic?
Yes, they are designed for heavy-duty, high-frequency industrial use.
Are insulated doors necessary for truck terminals?
Optional, depending on the type of cargo handled and environmental requirements.
Is automatic operation recommended?
Yes, especially for main loading bays with high vehicle traffic.
Get a Door Solution for Truck Terminals & Yards
Project Consultation & Technical Support
Guidance for door selection, sizing, and integration with terminal operations.
Bulk Supply & OEM Solutions
Suitable for trucking companies, logistics hubs, and large-scale yard projects.
|
|
|
