Industrial High Speed Door With Tight Sealing System And High-Frequency Operation For Clean Production Environments
Industrial High Speed Door With Tight Sealing System And High-Frequency Operation For Clean Production Environments
Product Introduction
Clean production environments require door systems that support fast access while maintaining strict environmental control. The Industrial High Speed Door is specifically designed for clean workshops where controlling airflow, dust, and contamination is essential for product quality.
Unlike conventional industrial doors, this industrial fast door operates at high speed and features excellent sealing performance. Rapid opening and closing cycles help minimize air exchange between zones, supporting stable production conditions in clean manufacturing environments. With a durable curtain structure and intelligent control system, the door is ideal for facilities requiring both efficiency and cleanliness.
Product Specifications:
| Parameter | Description |
|---|---|
| Material | PVC curtain / Galvanized steel / Stainless steel |
| Max Door Size | Door Width: 1000 mm - 6000 mm; Door Height: 1500 mm - 6000 mm |
| Operating Speed | Opening Speed: 0.6 - 1.2 m/s (adjustable); Closing Speed: 0.6 m/s (adjustable) |
| Curtain Material | 0.8 - 2.0 mm thick curtain, color options: Blue, Orange, Gray |
| Motor Power | 0.75-1.5KW (depending on size & speed) |
| Temperature Range | -10°C to 60°C (PVC); -10°C to 60°C (Steel/Stainless Steel) |
| Sealing Performance | High-quality brush seals on tracks; Bottom equipped with EPDM seal structure for better sealing |
| Wind Resistance | Max Wind Resistance: Class 6 (can be reinforced to Class 8) |
| Manual Function | In case of power failure or malfunction, the door can be manually opened with a wrench. |
| Power Requirements | 220V/13A Single-phase/50Hz-60Hz, IP54 control box, meets national electrical safety standards. |
| Insulation Protection | IP54 rating, providing water and dust protection, suitable for harsh environments. |
| Switching Methods | Standard one-button switch with emergency stop. Optional: Radar sensing, Ground magnetic sensing, Pull-rope switch, Remote control, etc. |
Key Features of Industrial High Speed Door
Hygienic Door Curtain Structure
The Industrial High Speed Door uses smooth PVC materials that are easy to clean and resistant to contamination.
-
Non-porous curtain surface
-
Dust-resistant material
-
Easy maintenance design
High Speed Operation
Fast door movement is essential for controlling environmental conditions.
-
Opening speed up to 1.2 m/s
-
Rapid closing cycle
-
Smooth and stable operation
Excellent Sealing Performance
The sealing system prevents dust and airflow between different areas.
-
Side guide sealing brushes
-
Flexible bottom sealing edge
-
Tight curtain alignment
Intelligent Door Control Options
Modern clean workshops require automated solutions.
-
Radar motion sensors
-
Push-button operation
-
PLC control system integration
Advantages for Clean Workshop Applications
Maintains Controlled Environments
Industrial High Speed Doors help maintain clean production areas by limiting airflow disturbance.
Improves Operational Efficiency
Fast door cycles reduce waiting time for workers and material transport.
Enhances Workplace Hygiene
Smooth curtain surfaces simplify cleaning and sanitation procedures.
Supports Continuous Production
Industrial fast doors enable efficient movement between clean zones and production areas.
Typical Applications
Clean Assembly Workshops
Used between production and packaging areas.
Electronics Manufacturing Facilities
Maintains controlled conditions for precision components.
Food Packaging Workshops
Helps maintain hygienic production environments.
Industrial Clean Processing Areas
Supports environmental control in specialized production zones.
FAQ
Why use Industrial High Speed Doors in clean workshops?
They help control air movement and maintain cleaner working environments.
Are industrial fast doors suitable for hygiene-sensitive areas?
Yes. Smooth PVC curtain surfaces are easy to clean and maintain.
Can the door operate frequently?
Industrial High Speed Doors are designed for high-frequency operation.
|
|
|
