Custom Made Stainless Steel Clean Door Airtight Cleanroom Door With Tempered Glass
China Manufacturer Custom Made Stainless Steel Clean Door Airtight Cleanroom Door With Tempered Glass
Introduction
Maintaining strict air control is essential in high-grade cleanroom environments. Our Airtight Steel Cleanroom Door is specifically engineered to deliver superior sealing performance, preventing air leakage and ensuring stable pressure differentials. Designed for industries where contamination control is critical, this door combines durable steel construction with advanced sealing technology, making it ideal for pharmaceutical, semiconductor, and laboratory cleanrooms.
Product Features
High-Performance Airtight Sealing System
The door is equipped with an automatic drop-down sealing mechanism and multi-point sealing structure. This ensures complete closure when the door is shut, effectively minimizing air leakage.
-
Maintains stable pressure differentials
-
Prevents cross-contamination between zones
-
Supports ISO 5–7 cleanroom standards
Durable Steel Structure with Long-Term Stability
The powder-coated steel panel combined with an aluminum honeycomb core provides excellent durability while maintaining lightweight performance.
-
Resistant to corrosion and wear
-
Maintains structural integrity under frequent use
-
Suitable for high-traffic industrial cleanrooms
Hygienic Design for Easy Maintenance
The smooth surface and flush-mounted observation window reduce dust accumulation and simplify cleaning procedures.
-
Easy to disinfect and maintain
-
Reduces contamination risk
-
Suitable for sterile environments
Industry Applications
-
Pharmaceutical cleanrooms
-
Semiconductor manufacturing facilities
-
Laboratory research environments
-
Biotechnology cleanrooms
-
Medical device production areas
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Steel Cleanroom Door (Swing Door / Automatic Sliding Door Optional) |
| Door Panel Thickness | 50 mm |
| Door Panel Material | 0.8 mm cold-rolled steel sheet with powder coating |
| Door Frame Material | 1.2 mm cold-rolled steel sheet with powder coating |
| Internal Filling | Aluminum honeycomb core |
| Observation Window Size | 400 × 600 mm |
| Observation Window Glass | Double-sided 5 mm clear tempered float glass |
| Opening Method | Push and Pull |
| Glass Window | Tempered |
| Opening Direction | Left / Right Inward / Outward |
| Size | Customized Size |
Contact Us:
Whatsapp:+8618021983369
Oem service:
Welcome customized size
We are experience factory for OEM&ODM service
FAQ
Q1: What makes an airtight cleanroom door different from standard doors?
A: Airtight doors feature enhanced sealing systems that prevent air leakage and maintain pressure balance.
Q2: Can this door be used in ISO 5 cleanrooms?
A: Yes, it is suitable for ISO Class 5 to Class 7 environments.
Q3: Is the sealing system durable?
A: Yes, it is designed for long-term industrial use with minimal maintenance.
Q4: Can the door size be customized?
A: Yes, dimensions and configurations can be customized based on project needs.
|
|
|
