Heavy Duty Steel Dock Leveler Structure With 380V Power For Industrial Warehouse
Heavy Duty Steel Dock Leveler Structure With 380V Power For Industrial Warehouse Applications
Product Introduction
The loading dock leveler is an essential piece of equipment for modern warehouses and logistics centers, designed to bridge the height difference between loading docks and trucks. It ensures safe, efficient, and smooth loading and unloading operations.
This hydraulic dock leveler features a heavy-duty steel structure and anti-skid checkered plate platform, providing reliable performance under high load conditions. As a versatile warehouse dock leveler, it supports various configurations including fixed dock leveler, powered dock leveler, and mechanical dock leveler options, making it suitable for a wide range of industrial applications.
Key Features of Loading Dock Leveler
Heavy Duty Steel Dock Leveler Structure
Built with high-strength materials for long-term industrial use.
- Anti-skid checkered steel plate
- Reinforced platform design
- Suitable for heavy duty dock levelers
Hydraulic Dock Leveler System
Reliable lifting performance for efficient operation.
- Hydraulic lifting mechanism
- Lifting speed: 0.05–0.09 m/s
- Stable and smooth operation
Fixed Dock Leveler Configuration
Designed for permanent installation in warehouse docks.
- Fixed dock leveler system
- Strong structural stability
- Low maintenance requirements
Anti-Slip Safety Platform
Improves safety during loading operations.
- Non-slip surface design
- Suitable for forklifts and pallet trucks
- Reduces accident risks
Wide Working Temperature Range
Suitable for various environments including cold storage.
- Working temperature: -35℃ to +50℃
- Reliable in cold chain logistics
- Durable in harsh environments
Product Specifications
| Rated bearing capacity of the platform | 6.0t (dynamic) | 8.0t (static) |
| Working temperature | -35℃~+50℃ | |
| Driving voltage | 380V,3phase,50HZ | |
| Main panel material | 8mm thick embossed anti slip plate | |
| Main panel support | C-type bending parts | |
| Building board material | 14mm thick embossed anti slip steel plate | |
| Bottom frame | #8channel steel and angle steel | |
| Safety barriers on both sides | 3mm steel plate and 1.2mm hot-dip galvanized steel plate | |
| Electric hydraulic system | Includes main lift cylinder | |
| Safety system |
|
|
| Collision avoidance system | Anti collision rubber block :two pieces,welded to the front end of the platform | |
Structural Diagram
Technical Parameters of Dock Leveler Hydraulic
Standard Specifications
- Voltage: 380V
- Size: 2000×2000×600 mm / 2000×2500×600 mm
- Material: Anti-skid checkered plate
- Color: Blue / Grey / Black / Customized
Optional Configurations
- lip dock leveler design
- poweramp dock levelers system
- automatic dock leveler control
- mechanical loading dock leveler version
Types of Industrial Dock Levelers Available
- Hydraulic Dock Leveler
- Mechanical Dock Leveler
- Vertical Dock Leveler
- Vertical Storing Dock Leveler
- Truck Dock Leveler
- Powered Dock Leveler
Advantages of Loading Dock Leveler
Improves Loading Efficiency
The loading dock leveler ensures smooth transition between dock and truck.
Enhances Warehouse Safety
Reduces risk during forklift operations.
Supports High Frequency Use
Designed for busy logistics centers and distribution hubs.
Compatible with Multiple Dock Systems
Works with dock shelters, dock doors, and logistics platforms.
Applications of Warehouse Dock Leveler
- Warehouse Loading Dock Areas
- Logistics Distribution Centers
- Industrial Manufacturing Facilities
- Cold Chain Warehouses
- Freight and Shipping Terminals
Why Choose Our Industrial Dock Levelers
Professional Manufacturing Experience
Years of expertise in industrial dock levelers production.
Strict Quality Control System
Certified with ISO 9001 / CE standards.
Customization Capability
Support customized sizes, colors, and configurations.
Reliable Export & Delivery
Experienced in global logistics and packaging.
Competitive Factory Price
Direct manufacturer supply with stable quality.
FAQ – Loading Dock Leveler
What is a loading dock leveler?
A loading dock leveler is a platform that bridges the gap between a warehouse dock and a truck for safe loading.
What types of dock levelers are available?
Options include hydraulic dock leveler, mechanical dock leveler, vertical dock leveler, and powered dock leveler.
Is the dock leveler suitable for heavy-duty use?
Yes, it is designed as a heavy duty dock leveler for industrial environments.
Can it work in cold storage?
Yes, it operates in temperatures from -35℃ to +50℃.
What is the difference between hydraulic and mechanical dock leveler?
A dock leveler hydraulic uses a powered system, while a mechanical dock leveler relies on manual operation.
|
|
|
