1500-2500 Nits Transparent Film LED Display 1920x1080 Full HD 2.5mm Pixel Pitch
Indoor crystal film display screen for high-quality visual experience.
-
Weight:
1.3kg
-
Brightness:
2000/4000CD/㎡
-
Refresh rate:
≥3840Hz
| Model | CHEER-TF6 | CHEER-TF8 | CHEER-TF10 | CHEER-TF15 |
| Module Size | 816×384mm | 1000×400mm | 1000×400mm | 990×390mm |
| LED light | CH1515 | CH1515 | CH1515 | CH2121 |
| Module pixel | 136×64=8704dots | 125×50=6250dots | 100×40=6250dots | 66×26=1716dots |
| Pixel/m² | 27777 | 16500 | 10000 | 6625 |
| Brightness | 2000/4000CD/m² | 2000/4000CD/m² | 2000/4000CD/m² | 2000/4000CD/m² |
| Permeability | 90% | 92% | 94% | 94% |
| Angle of view | 160°/160° | 160°/160° | 160°/160° | 160°/160° |
| Peak power | 400w/m² | 400w/m² | 400w/m² | 400w/m² |
| Average power | 200w/m² | 200w/m² | 200w/m² | 200w/m² |
| Weight | 1.3kg | 1.3kg | 1.3kg | 1.3kg |
| Thickness | 2.5mm | 2.5mm | 2.5mm | 2.5mm |
| Refresh rate | 3840Hz | 3840Hz | 3840Hz | 3840Hz |
| Grayscale level | 16bit | 16bit | 16bit | 16bit |
| Typical value of life | 100000H | 100000H | 100000H | 100000H |
![]()
Mini LED and Breakpoint continuation
The combination of light and drive, independent research and development, high reliability, industry leading
![]()
Easy installation
No steel structure is required, just stick the thin screen slightly and connect the power signal.
![]()
High Transmittance
Use the integrated MiniLED lamp beads to improve its own permeability. Use invisible grid circuit to improve its permeability
![]()
Flexibility
Applies to any surface Fig. 1 Real shot of module curled into a circle Surface case
![]()
Flame retardant and UV resistant
Grade V1 flame retardant Uv resistance without yellowing >8 years
