Invisible Holographic LED Display Wall Mounted Full Color 50 Watts High Brightness
The same series as the crystal transparent screen, much more cost-effective proposal for indoor transparent display.
| Parameter | M3 Glass Mounting | M6 Glass Mounting |
|---|---|---|
| Pixel Pitch (mm) | 3.91*3.91mm | 3.91*7.82mm |
| Visual Transparency | 90% | 95% |
| Pixel Density (dot/m²) | 65536 | 32768 |
| Cabinet Size (mm) | 1000×2501500×250 | 1000×2501500×250 |
| Cabinet Resolution (dot) | 256x6484X64 | 256x32384x32 |
| Weight (Kg/m) | 6 | 6 |
| Brightness (cd/m²) | ≥5000 | ≥5000 |
| Encapsulation Type | Driver-integrated Encapsulation | Driver-integrated Encapsulation |
| Scanning Method | Single-point Single-control, Static Driving | Single-point Single-control, Static Driving |
| LED Lifespan | ≥100,000 hours | ≥100,000 hours |
| Gray Scale | 65536 | 65536 |
| Maximum Power Consumption (W/m²) | 800 | 800 |
| Average Power Consumption (W/m²) | 200 | 200 |
| LED Control System | Synchronous/Asynchronous | Synchronous/Asynchronous |
| Input Voltage | AC100~240V 50/60Hz | AC100~240V 50/60Hz |
| Module Operating Voltage | DC4.2V±0.2V | DC4.2V±0.2V |
Our patented zero-code technology and extensive IP portfolio set a new global standard for invisible screen displays.
Unparalleled Transparency
With up to 90% transparency, the Holographic Invisible Screen seamlessly integrates into any environment.
Versatile Installation
Easily installed without a back frame and can be cut or bent to fit any space.
-
![]()
Easily installation
Lightweight(2kg/m2)
Easily installed without a back frame and can be cut or bent to fit any space.
Thin(1-3mm)
Seamlessly integrates with glass and other surfaces.
Up to 90% Transparency
Delivers an unobtrusive, fully transparent display experience.
-
![]()
High brightness
The brightness can be 1500-3000CD/SQM, it can meet all indoor requirement. 14-16 bits, high gray scale. 1920HZ - 3840HZ, high refresh rate.
-
![]()
- Flexible and cuttable, adaptable to various irregular and complex scenarios
- Ultra-light and ultra-thin, double-sided mounting on glass with minimalist installation and maintenance
- Visible, semi-invisible, invisible — 90% transparency + 9000:1 contrast ratio for high-definition images
- Integrated unit sizes: 11m, 22m, 1*2m — free splicing without restrictions
- 90% high transparency, barely blocking natural light
- High brightness of 5000cd/m², vibrant colors even under direct sunlight
- Commercial Complexes: Glass curtain walls, atriums, glass railings, glass showrooms, observation elevators, etc.
- Brand Chains: Tea and catering stores, bakeries, clothing/jewelry shops, 3C experience stores, bank branches
- Advertising & Media: Transportation hubs such as airports, high-speed rail stations, subway stations, bus terminals
- Performing Arts & Stage Design: Bars/clubs, stage backdrops, variety shows, cultural tourism landscapes
