Dongfeng 4 Ton Rollback Tow Truck with Crane Flatbed Wrecker Wheel Lift Carrier
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
30 Days
Brand:
EHY
Product Description
Dongfeng Rollback Tow Truck Mounted Crane Wrecker Flatbed Wheel Lift Car Carrier
Product Description:
- Purpose of 4ton flatbed tow truc: wrecker/recovery truck/towing truck is used for towing broken cars,vehicle on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
- Optional brand of 4ton flatbed tow truc:howo,Dongfeng,JAC,JMC,Foton,Shacman.
- Spare parts of 4ton flatbed tow truc: Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
- Capacity range of flatbed tow truc:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
- The customers can choose to install the crane.
| General Technical Parameters | |||
| Overall Dimension | 5995x2300x2250 (mm) | ||
| Gross Vehicle Weight | 4495kg | ||
| Curb Weight | 3800kg | ||
| Chassis Specification | |||
Chassis Parameters | Chassis Brand | JAC | |
| Cabin | Single, Left Hand Driving | ||
Engine | Model | 4 Cylinders | |
| Power | 88 KW/120HP | ||
| Emission Standard | EURO II | ||
| Displacement | 2771ML | ||
| Fuel Type | Diesel | ||
| Gearbox | 5 Forward & 1 Reverse Gear | ||
| Front and Rear Axle Load | 3T/6T | ||
| Wheel Base | 3308(mm) | ||
| Overhang( Front/Rear) | 1015/2450(mm) | ||
| Angle(Approach/departure) | 24/9(°) | ||
| Brake System | oil brake | ||
| Steering Gear | Power Assistant | ||
| Tire | 7.00R16, 6 Pieces with 1 Spare Tire | ||
| Maximum Speed | 90 (km/h) | ||
| Superstructure | |||
Flatbed | Dimensions | 4200x2320 (mm) | |
| Max. Loading Weight | 4000(kg) | ||
| Operating Stroke | 2700 (mm) | ||
| Min. Angle of Slope | 8(°) | ||
| Platform Height from the Ground | 1070(mm) | ||
Winch | Quantity | 1pc | |
| Winch Rating Pulling Capacity | 4000 (kg) | ||
| Length of Steel Cable | 25 (m) | ||
Hoisting Organ | Rating Under-Pulling Capacity | 6000 (kg) | |
| Rating Under-Hoisting Capacity | 2000 (kg) | ||
| Fully Extended Max Under-Hoisting Capacity | 1600 (kg) | ||
| Max Under-Hoist Useful Length | 1640 (mm) | ||
Remarks | 1. Equiped with One Set of Auxiliary Wheels 2. Bandages 4pcs 3. Yellow Warning Lamp 1pc 4. Double Side Hydraulic Operation 5. Can Tow 2 Cars | ||
