Dongfeng 25m Hydraulic Aerial Platform Truck Construction Equipment High Altitude Working
- Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
- The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
- Full Computer Control System with Danger Waring System.
- LCD Screen in Both the Bucket and Truck to Display the Working Status.
- Rectangular Shape Arms to Increase the Arm Strength.
- V Shape Leg, H Shape Leg can Adapted to Different Road Condition Increasing the Stability.
| 24Meter Aerail Platform Truck | |
| Overall dimensions | 8450×2050×3050 mm |
| Maximum Height | 24 meters |
| Maximum operation radius | 8.0 meters |
| Gross vehicle weight | 6705 kg |
| Mass in working order | 6380 kg |
| Wheel base | 4200 mm |
| F/R track base | 1015/2280mm |
| Approach/departure angle | 24/10° |
| Cabin | Dongfeng, Right/Left Hand Driving, with A/C. |
| Engine | Diesel Engine B140 33, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling |
| Displacement/ HP | 3900 Liter / 140HP |
| Max speed | 90 km/h |
| Tire specification | 900R20 |
| Traction system | 4x2 |
| Number of axles | 2 |
| 1. Max operation height:18m (including 1.7meter person height, net height is 16.3meter), 2. Max operation radius≤7.9m, 3. Max working platform height≤16.3m, 4. Working platform rating loading≤200kg, 5. Working platform rating allowable passengers=2, 6. Working platform dimension:1100*570*1000mm, 7. 360°turning(left or right), 4 H-shape legs. 8.The cage be operated both in the air and on the earth |
