4x2 600P Double Cabin Manual 16m Bridge Inspection Aerial Platform Truck 120hp
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
30 Days
Brand:
EHY
Product Description
4X2 600p Double Cabin Manual 14m-15m Bridge Inspection Aeria Platform Trucks
- Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
- The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
- Full Computer Control System with Danger Waring System.
- LCD Screen in Both the Bucket and Truck to Display the Working Status.
- Rectangular Shape Arms to Increase the Arm Strength.
- V Shape Leg, H Shape Leg can Adapted to Different Road Condition Increasing the Stability.
Product Description
| Aerial Platform Truck | |
| Overall dimensions | 8450×2050×3100 mm |
| Wheel base | 3800 mm |
| F/R track base | 1015/2280mm |
| Approach/departure angle | 24/10° |
| Front / Rear Axle | 2Ton / 4.8Ton |
| Cabin | 600P cabin, Double Row, Left Hand Driving, with A/C, Radio |
| Engine | 4KHF-TCG40, Diesel type, 4 Stroke, 4 Cylinder in line, Turbocharged, Inter cooling, Euro IV |
| Displacement/ HP | 2999ml / 120hp |
| Gearbox | 5 foward &1 reverse |
| Steering Gear | Hydraulic Power Steering |
| Max speed | 90 km/h |
| Tire specification | 7.00-16, 6 Pieces |
| Traction system | 4x2 |
|
Equipment |
1. Max operation height:16m (including 1.7meter person height, net height is 14.3meter), 2. Max operation radius≤ 9.2m, 3. Max working platform height≤12.5m, 4. Working platform rating loading≤200kg, 5. Working platform rating allowable passengers=2, 6. Working platform dimension:1100*570*1000mm, 7. 360°turning(left or right), 4 H-shape legs. 8.The cage be operated both in the air and on the earth 9. Control System: Manually 10. Hook Lifting Height: 6meters, Hook Lifting Weight: 800kg |
