Dongfeng 4x2 10 Ton Diesel Dump Tipper Truck 129HP Yuchai Engine for Mining Construction
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
Negotiable
Brand:
EHY
Product Description
Dongfeng 4*2 10tons Diesel Light Dump/Tipper Truck Minery Transportation Construction Lorry Truck
Product description:
- Truck chassis brand of dump truck: SINOTRUK HOWO, CAMC, SHACMAN, JAC, NORTH-BENZ, IS UZU, FOTON, etc.
- Tipping Model of dump truck: Front-tipping, Middle-tipping.
- Hydraulic oil cylinder brand of dump truck: International brand HYVA or Chinese famous brand.
- High tensile steel for dumper materia of dump truck: 4mm, 6mm, 8mm,10mm or as per customer's request.
- Used in Construction or Mineral site for Transportation of mineral, stone, sand, garbage and etc.
Specification of dump truck:
| ITEM | UNIT | PARAMETERS |
|---|---|---|
| Product | Dump truck | |
| Cabin | Left hand drive, without air conditioning | |
| Body internal dimensions | mm | 6500×2490×2850 |
| Fact loading capacity | kg | 10000~15000 |
| GVW | kg | 9900 |
| Curb weight | kg | 5500 |
| Dump body overall dimensions | mm | 4500×2300×800 |
| Wheelbase | mm | 3950 |
| F/R track base | mm | 1340/1590 |
| Approach/departure angle | 25/12 | |
| Power | 96KW/129Hp, YUCHAI | |
| Max speed | km/h | 90 |
| Tire specification | 9.00 Nylon | |
| Traction system | 4×2 | |
| Number of axles | 2 | |
| Engine Type | YUCHAO 129HP | |
| Transmission | 5 speed manual transmission | |
| Electric system | V | 24 |
| Operation control sysytem | Electrically hydraulic control | |
| Allowance passengers in cab | 2 | |
| Dump body | Size: 4500×2300×800 Side and front thickness: 3mm, Floor thickness: 4mm. Middle tipping; A complete set of Chinese famous brand hydraulic system |
|
