Shacman F2000 8x4 Heavy Dump Truck 40 Ton Capacity 12 Wheels Tipper with Weichai 385HP Engine
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
35 Days
Brand:
EHY
Product Description
Product description
Shacman tipper truck 12 wheeles dump body 40ton 50ton dump tipper truck
Product description:
- Dump truck brand: SINOTRUK HOWO, CAMC, SHACMAN, JAC, NORTH-BENZ, FOTON, etc.
- Tipping Model of dump truck: Front-tipping, Middle-tipping.
- Hydraulic oil cylinder brand of dump truck: International brand HYVA or Chinese famous brand.
- High tensile steel for dumper materia of dump truck: 4mm, 6mm, 8mm,10mm or as per customer's request.
- Used in Construction or Mineral site for Transportation of mineral, stone, sand, garbage and so on.
Specification of dump truck:
| ITEM | PARAMETERS | |
| Brand | SHACMAN | |
| Model | F2000 | |
| Product | Dump truck | |
| Cabin | Left hand drive, without air conditioning | |
| GVW(kg) | 31000 | |
| Curb weight(kg) | 14600 | |
| Front axle | 9.5T man technology | |
| Rear axle | 16Ton man casting axle, final ratio 4.769 | |
| Wheelbase(mm) | 1800+3575+1400 | |
| Overall dimensions(mm) | 10329×2490×3450 | |
| F/R suspension(mm) | 1525/2054 | |
| F/R track base(mm) | 1939/1939, 1850/1850 | |
| Approach/departure angle(°) | 28/20 | |
| Max speed(km/h) | 85 | |
| Clutch | 430 diaphragm type | |
| Fuel tank volume | 400L(alloy) | |
| Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
|
| Steering gear | Power steering, hydraulic steering with power assistance | |
| Tire quanity | 12 pcs with 1 spare tire | |
| Tire specification | 12.22R20 | |
| Transmission | 9 speed forwarder, with 1 reverse | |
| Cab | With air conditioning and a sleeper | |
| Traction system | 8×4 | |
| Number of axles | 4 | |
| Engine model | WP12.430E201(WEICHAI) | |
| Displacement | 11.596L | |
| Power | 283kw/385hp | |
| Emission standard | EURO 2 | |
| Gearbox | 12JSD200T-B+QH50, FAST gearbox | |
| Fuel type | Diesel | |
| Max torque | 2060N.m | |
| Cylinder number | 6 | |
| Electric system(V) | 24 | |
| Operation control sysytem | Electrically hydraulic control | |
|
Dump body |
Size: 7400×2300×1500 Max loading weight: 40ons Material: carbon steel Q235 Side thickness: 6mm, bottom thickness: 8mm. Hyva front tipping; China famous oil cylinder cylinder Color is optional for customer's request |
|
