HOWO 10 Wheeler Dump Truck 6X4 Heavy Duty Truck 10 Tyre Tipper Truck 336 HP 340/371HP 375
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
Negotiable
Brand:
CLW
Product Description
HOWO Dump Truck With 10 Wheels 6X4 Hot Sale At Africa Best Condition Heavy Duty Truck 10 Tyre Tipper Truck 336 HP 340/371HP 375
Product Description
- Dump truck brand:SINOTRUK HOWO,CAMC,SHACMAN,JAC,NORTH-BENZ,FOTON...
- Tipping Model:Front-tipping,middle tipping dump truck,HYVA or Chinese brand hydraulic oil cylinder brand
- High tensile steel for dumper materia,4mm,6mm,8mm, 10mm oer as per client's request and purpose.
- construction site for transportation of mineral,stone,sand and so on.
Specification
| Condition | New condition/Left hand drive/6x4 | ||
|
Chassis |
Brand | SHACMAN | |
| Model | F2000 | ||
| Curb weight(kg) | 12400 kg | ||
| Axle loading(Front/Rear)(kg) | 7000/18000 kg | ||
| Wheelbase(mm) | 3775+1400 mm | ||
| Dimensions(mm) | 8560*2490*3430 mm | ||
| Wheel track (front/rear) (mm) | 2036/1860/1860 mm | ||
| Front/Rear overhang(mm) | 1525/1660 mm | ||
| Approach/Departure angle(°) | 28/18 | ||
| Max. driving speed(km/h) | 77 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
| Fuel tank volume(L) | 300 L | ||
|
Brakes |
Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10pcs with one spare tire | |
| Specifications | 11R22.5 | ||
| Transmission | Manual type, 9 Forwards and 2 reverse | ||
| Cab | It can accommodate three people, With Air conditioner. | ||
|
Engine |
Fuel type | Diesel | |
| Displacement(ml) | 9726 ml | ||
| Power(kw) | 235 kw | ||
| Horsepower(HP) | 320 HP | ||
| Cylinder number | 6 | ||
| Emission standard | Euro 2 | ||
|
Upper |
Size(mm) | 5400*2300*1600 mm | |
| Max. Loading weight(kg) | 25 tons | ||
| Button Thickness(mm) | 8.0 mm | ||
| Side plate Thickness(mm) | 6.0 mm | ||
| Material | Q235 Carbon steel | ||
| Tipping type | Middle Tipping | ||
| Oil cylinder brand | China local brand | ||
| Oil cylinder size(mm) | 220 mm | ||
| Remarks | 1. Color is optional | ||
