3 Seats Tipper Dump Truck 15 Ton Dongfeng Heavy Duty Dump Truck
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
Negotiable
Brand:
CLW
Product Description
| Truck Specification | ||
| truck model | CLW3040Z1 | |
|---|---|---|
| Cab | Dongfeng single row cab, with power steering. without a/c | |
| Driving Type | 4*2 Left hand driving | |
| Max Speed (km/h) | 90 | |
| Overall dimension(mm) | 5995*2055*2360 | |
| GVW(kg) | 4495 | |
| Mass in working order (kg) | 2715 | |
| Wheelbase(mm) | 3300 | |
| F/R track base (mm) | 1543/1540 | |
| F/R overhang (mm) | 1075/1475 | |
| Approach/Departure Angel | 23/18 | |
| Tire | 7.50-16 (6+1) | |
| Clutch | Single-plate dry diaphragm spring clutch | |
| Steering | Hydraulic steering with power assistance | |
| Gear box | 5-speed font +1 rear reverse | |
| Bridge | Front axle | 2T |
| Rear axle | 4T | |
|
Enging |
Model | CY4102-C3F |
| Fuel Type | Diesel fuel | |
| Type | Water-cooled, four-stroke,, direct injection, turbocharged | |
| Exhaust(ml) | 3856 | |
| Max output power/rotate speed (hp /rpm ) | 95/3200 | |
| Braking system | Service Brake | Compressed air brake |
| Park Brake | Spring energy | |
| Auxiliary brake | engine exhaust brake | |
| Eletric system | 24v | |
| Upper-Body specification | ||
| Dump box dimension (L*W*H)(mm) | 4200*1900*550 | |
| Dump box material | Carbon steel | |
| Dump box thickness (mm) bottom/side | 4/3 | |
| Hydraulic cylinder | Middle-placed T-Shape cylinder | |
| Dump box color | According to customer's requirement | |
