SINOTRUK HOWO 30-35 Ton Dump Tipper Truck 6x4 Mining Construction Heavy Duty
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
35 Days
Brand:
EHY
Product Description
Product description
China 30 Tons 35 Tons HOWO Dump Tipper Truck Minery Construction Mining Transportation Dumping/Tipping truck
Product description:
- Dump truck brand:SINOTRUK HOWO,CAMC,SHACMAN,JAC,NORTH-BENZ,FOTON...
- Tipping Model:Front-tipping,middle tipping dump truck,HYVA or Chinese brand hydraulic oil cylinder brand
- High tensile steel for dumper materia,4mm,6mm,8mm, 10mm oer as per client's request and purpose.
- Used in construction site for transportation of mineral,stone,sand and so on.
Specification of dump truck:
| Condition | New condition/Left hand drive/6x4 | ||
Chassis | Brand | SINOTRUK | |
| Model | HOWO | ||
| Curb weight(kg) | 12100 kg | ||
| Loading weight | 30000 kg | ||
| Axle loading(Front/Rear)(kg) | 9000/16000/16000kg | ||
| Wheelbase(mm) | 3800+1350 mm | ||
| Dimensions(mm) | 8300*2496*3450 mm | ||
| Wheel track (front/rear) (mm) | 2036/1860/1860 mm | ||
| Front/Rear overhang(mm) | 1500/1650 mm | ||
| Approach/Departure angle(°) | 19/17 | ||
| Max. driving speed(km/h) | 95 km/h | ||
| Clutch | Single-plate dry diaphragm spring clutch | ||
| Fuel tank volume(L) | 300 L | ||
| Brakes | Air brake | ||
| Steering Gear | ZF8118 | ||
Wheel & types | Rims | 8.25-20, 10 hole-steel | |
| Quantity | 10pcs with one spare tire | ||
| Specifications | 12R22.5 | ||
| Transmission | Model HW19710, 10 Forwards and 2 reverses, with PTO | ||
| Cabin | HW70, HW76 | ||
Engine | Brand | SINOTRUK HOWO | |
| Model | WD615.47 | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 9726 ml | ||
| Power(kw) | 273 kw | ||
| Horsepower(HP) | 371HP | ||
| Cylinder number | 6 | ||
| Emission standard | Euro 2 | ||
| Description | 4 stroke direct injection diesel engine 6 cylinder in-line with cooling, turbo-charging & intercooling | ||
Upper | Type | U type or rectangle type | |
| Size(mm) | 5400*2300*1300 mm | ||
| Max. Loading weight(kg) | 30tons~35 tons | ||
| Button Thickness(mm) | 6.0 mm | ||
| Side plate Thickness(mm) | 4.0 mm | ||
| Material | Q235 Carbon steel/ Har-dox 450/ NM 450 | ||
| Tipping type | Middle Tipping | ||
| Oil cylinder brand | China local brand | ||
| Oil cylinder size(mm) | 220 mm | ||
| Remarks | 1. Color is optional | ||
